Polyurethane Sandwich Wall Panel

Name: Polyurethane Sandwich Wall Panel
Brand: HUAHAI
SKU: 143335792
Availability: InStock

Tengzhou City Huahai New Thermal Insulation Material Co., Ltd.

Negotiable MOQ: 1000 Square Meters (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Shandong, China

Brand Name:

HUAHAI

Model Number:

HHWA

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shandong, China

Brand Name HUAHAI

Model Number HHWA

Material Steel

Specifications

polyurethane sandwich wall panel
1.dampproof,waterproof
2.long working life
3.heat&sound insulation
4.easy to assemble

polyurethane sandwich wall panel

@ product description :

Density	38-45kg/m3 (no deformation under high pressure)
Thermal conductivity	0.021w/m.k
Impact strength	>150Kpa
Water absorption rate	<0.018
Temperature range	-200-150 °C
Materials	Double color steel + pu(polyurethane ) foam panel
Total Thickness	50mm/75mm/100mm/120mm/150mm/180mm/200m
Colorsteelthickness	0.35mm/0.4mm/0.45mm/0.5mm
Length	can be cut as the customer’s requirement
Covering steel color	RAL 9002 Gray white color
Width	985mm/960mm/1005mm
Technique	a world-class continuous production line
Payment terms	by L/C or T/T 50%as the deposit ,another 50% transfer to our account before receiving the copy of B/L

@ The characteristics of polyurethane foam sandwich panel (PU sandwich panel):

High load intensity , low water absorption ,long service life , outstanding thermal insulation and great stability in low and high temperature
Light weight , non-toxic,odorless and eco-friendly , good supporting , heat resistance and sound-insulation .
can cement with steel plates , cements ,fiberboards bricks and many kinds of materials and nomally would not fall off with great thermal insulation and waterproof properties .
The unique foaming craft enables the panel to have low thermal conductivity and good size stability . the panel is suitable for construction in low or high pressure .
Light weight:10-14 kg/m2
High thermal stability : no obvious change of volume and intensity when the temperature is lower than -150 °C
Low thermal conductivity :63J when the density is 0.03kg/m3
The installation is convenient and flexible with no need of large-scale devices to shorten the construction period and lower the cost .
Great temperature-resistance : no deformation from -150 °C to -150 °C

Application field:

Because of its hidden connecting design, this panel has good visual effect, widely used in making wall of workshop, building office etc.

Have acquired “the Chinese Green Environmental Products ”Title
