Gasoline Engine YF

Liaocheng Yangfine Jeonil Machinery Co., Ltd.

Negotiable MOQ: 2 Sets (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Dimension(L*W*H):

362*380*335(mm)

Weight:

26.00kg

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Dimension(L*W*H) 362*380*335(mm)

Weight 26.00kg

Fuel Other, Gasoline,diesel

Usage Other, Industrial

Specifications

Robin gasoline engine fit to concrete vibrators, water pump.
can be inserted using,Cylinddrical ,Square Coupling,Hayashi

source: 110V/220V/380V/50HZ
Power: 1.5Kw(2.0Hp)
speed: 50HZ(2850rpm)/60HZ(3450rpm)
fuel: gasoline,diesel

be used with the concrete vibrators and the pump.

vibrator can be inserted using,Cylinddrical ,Square Coupling,Hayashi coupling

Model	EY15	EY20	EY28
Type	air-cooled, 4-cycle single cylinder, side valve, gasoline engine
Displacement	143cc	183cc	273cc
Continuous output	1.64kw/3000min (2.2HP/3600RPM) 2.01kw/3600min (2.7HP/3600RPM)	2.24kw/3000min (3HP/3000RPM) 2.61kw/3600min (3.5HP/3600RPM)	4.10kw/3600min (5.5HP/3600RPM)
Maximum output	2.61kw/4000min (3.5HP/3600RPM)	3.73KW/4000min (5HP/4000RPM)	5.5kw/4000min (7.5HP/4000RPM)
Direction of rotation	Counter clockwise facing P.O.T Shaft
Lubricant	Class SC or higher grade SAE#20 #30 #40
Fuel	Unleaded Gasoline,Diesel
Fuel tank capacity(L)	2.8L	3.8 L	5.5 L
Spark Plug:	NGK B-6HS		E6TC
Starting system	Recoil
Shipping weight(kg)	14kg	16kg	22kg
Packing size (LWH)(mm)	294x332x368	303x332x392	347x400x400
