power trowel
Description
Use mainly in concrete floating and finishing, with different types of blades and pans used, through troweling and weight of the machine to produce a flat, level and dense surface.
The enlarged diameter of the guard ring allows troweling in larger areas.
PT24 suitable to use all final screeds and refurbishment woks,mostly use in working through doorways in finish buildings.
PT36 use all common applications such as factories warehouses and all other general flooring contracting work.
Technical Specifications
Model | YFPT24-H | YFPT24-R | YFPT36-H | YFPT36-R |
Combo Blade Size (L*W)mm | 230*120 | 350*150 | ||
No.of Blades | 4 | 4 | ||
Guard ring diameter (mm) | 610 | 950 | ||
Max.Blade Pitch Angle- | 20 | 30 | ||
Blade Operating Speed-rpm | 85--138 | 61--131 | ||
Engine | HONDA | ROBIN | HONDA | ROBIN |
Engine Model | Honda GX160 | ROBIN EY20 | Honda GX160 | ROBIN EY 20 |
Engine Type | Air-Cooled 4 Stroke Gasoline Engine | |||
Power output(HP)/rpm | 5.5/3600 | 5.0/3600 | 5.5/3600 | 5.0/3600 |
Engine Fuel | Unleaded octane 86 Gasoline | |||
Weight (kg) | 56 | 58 | 82 | 84 |
Dimension(L*W*H)(MM) | 950*610*720 | 2100*950*1010 | ||
Factory
Features :
1, Over-built gearbox assures long life.
2, Heavy-weight design to assures a superior finish.
3, Height adjustable handle, dead-man switch available , assures operator comfort and easy control.
4, Centrifugal safety switch, shuts the engine down in the event of the operator loosing control of the unit.
5, Screw control ensures precise blade adjustment.
