Inverter TIG welding machine
Features
FEATURES:
♦Adopt advanced MOSFET technology,energy-saving.
♦Anti-stick,thermostatic protection ,automatic
voltage compesation capablility,less splash.
♦High efficency,light,compact,easy to operate.
♦Suit for various welding rods such as acidity,
alkalescence and heat-resisting steel,mainly
use in welding carbon steel,stainless steel,
alloy steel and cast iron .
♦Accessories:electrode holder,earth clamp,
brush/hammer,prtective mask,carton box.
Technical parameter
| TIG-160AR | TIG-180AR | TIG-200AR | |
| 1PH 230V | 1PH 230V | 1PH 230V | |
| 50/60Hz | 50/60Hz | 50/60Hz | |
Rated Input Capacity | 5.3KVA | 6.2KVA | 7.1KVA | |
| 60V | 60V | 60V | |
| 10-160A | 10-180A | 10-200A | |
| 60% | 60% | 60% | |
| F | F | F | |
Rated work voltage | 26.4V/MMA | 27.2V/MMA | 28V/MMA | |
| 85% | 85% | 85% | |
| cosφ0.93 | cosφ0.93 | cosφ0.93 | |
Protection Degree | IP21S | IP21S | IP21S | |
| Fan | Fan | Fan | |
| 49x25.5x33CM | 49x25.5x33CM | 49x25.5x33CM | |
| 9.2KG | 9.2KG | 9.3KG |
MMA Welding Details
MMA welding (metal arc) does not require shielding gas; protection for the weld pool comes from the electrode cover which melts during welding, and forms a protective layer of slag on the weld pool. When the welding is completed and the layer of slag is removed, the finished weld will be disvocered underneath.
MMA welding is the oldest and still the most commonly used arc welding process, although the proportion of MMA use is decreasing as gas-shiedled welding process is becoming more popular.
MMA welding is, however, an irreplacable method for instace when welding outside in windy conditions where using shiedling gas would be difficult. Another important benefit is that electrodes can be bought everywhere, also in small package.
UTOT's range of MMA welding machines offers DC inverter constant-current type, AC Arc transformer type and AC/DC type machines for all user groups from home users to extensive industrial application.
