Home > Products > Woodworking Machine > AUTO SIX ROWS MULTI-BORING MACHINE BJK130AZS With Max. Processing Pitch 2450x672mm And Min. Processing Pitch 140x32mm
AUTO SIX ROWS MULTI-BORING MACHINE BJK130AZS With Max. Processing Pitch 2450x672mm And Min. Processing Pitch 140x32mm
Negotiable
/ Piece
1 Piece(Min. Order)
- Qingdao Port
- T/T Credit Card
You May Like
-
Horizontal & Vertical Sander SH436 With Motor 370W And Belt Size 100x914mm
-
6" BELT & 10" DISC SANDER SH2515 With Motor 750W And Belt Size 152x1219mm
-
6" BELT & 9" DISC SANDER SH2315 With Motor 550W(750W) And Belt Size 150x1219mm(6"x48")
-
SINGLE BELT ROUND ROD SANDER MM2012 With Driving-wheel Velocity 1420r/min And Abrasive Band Line Speed 890mm/min
-
GURVED ROUND ROD MACHINE MM2005 With Cutting Diameter 10-60mm And Feeding Speed 3-10m/min (speed Control of Motor)
-
Automatic Sawllowtail Mortise SHSK50-Z With Maximum Working Width 500mm And Max Thickness 22mm
Product Details
| Condition | New | CNC or Not | Normal | |
| Spindle Speed | 2800r/min | Place of Origin | Shandong, China | |
| Brand Name | SHOOT | Model Number | BJK130AZS | |
| Voltage | 380V | Power(W) | 18KW | |
| Weight | 2550kg | Dimension(L*W*H) | 4000x3000x1650mm | |
| Certification | CE |
Product Description
| AUTO SIX ROWS MULTI-BORING MACHINE | |
| FEATURE | |
| More Powerful-High-quality motor with strong motivity constantly, it can run at full capacity in long time. | |
| Faster-Automatic feeding device can save the labour cost and upgrade the efficiency at the same time. | |
| More Accurate-Synchro numerical control makes accurate double-axletree orientation come true. And it controls the speed of drilling and material offering by program. | |
| It changes the traditional manuel model. | |
| Upgrades the efficiency evidently. | |
| Independent automatic feeding device makes more accurate. | |
| Automatic feeding device use independent motor and adjustable frequency converter, which enable to adjust the speed in different wood workpiece, independent motor supply strong motivity constantly. Multi-touching switch makes sure that the feeding processing is accurate positioning. | |
| MODEL | BJK130AZS |
| Max. drilling diameter | max=35mm(Single drill)/max=13mm(Multi drill) |
| Max. drilling depth | H max=60mm |
| Max. processing pitch | 2450x672mm |
| Min. processing pitch | 140x32mm |
| Total number of drilling rows | 21x2+11x8 |
| Total number of drilling shafts | 130 |
| Installing diameter to the drilling | 10mm |
| Distance between spindle | 2500mm |
| Working pressure | 0.6~0.9Mpa |
| Total power of motor | 18kw |
| Spindle speed | 2800r/min |
| Overall size | 4000x3000x1650mm |
| Feeding speed | 60m/min |
| Weight | 2550kg |
