Precision Panel Saw Machine With Saw and Moulder SHM6132-TZ.GB With Dimensions Sliding Table 3200x380mm

Precision Panel Saw Machine With Saw and Moulder SHM6132-TZ.GB With Dimensions Sliding Table 3200x380mm photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New, New
Type:
Other, Table Panel Saw, Table Panel Saw
Use:
Other, Woodworking, Woodworking
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Port
Delivery Detail:
Delivery time depends on order quantity.
Type Other, Table Panel Saw, Table Panel Saw
Use Other, Woodworking, Woodworking
Style Other, Horizontal, Horizontal
Place of Origin Shandong, China
Brand Name SHOOT
Model Number SHM6132-TZ.GB
Power(W) 750/2200/4000W
Dimension(L*W*H) 2200x1170x1100 mm
Weight 740/870KG
Certification CE



Precision Panel Saw Machine with Saw and Moulder
Feature
Apply to processing all kinds of density boards,shaving boards,wood-base panels,ABS panels,PVC panels ,organic glass plates and solid wood and others with wood structure and simiar hardness,
Movable table guide track is plating chromium steel balls structure,exact and durable.
Made of high-strength extruded aluminum alloy,movable table is high in strength and won’t bend.
With oxidation treatment,movable table surface is beautiful and hardwearing.
Tilt angles of main and scoring saw blades are displayed directly by precision inclinometer.
*Digital indicator is option
*ALTENDORE Aluminium Sliding Table
*Two Kinds of Function: Saw and Moulder
ModelSHM6132-TZ.GB
Dimensions sliding table3200X380mm
Max.cut capacity3200mm
Max.width of cut between saw blade and rip fence1250mm
Saw blade300mm(250-300)
Max.height of cutφ300mm75mm
Max.height of cut with saw bladeφ300mm at 45°55mm
Speed of main saw blade4000rpm
Spindle diameter30mm
Tilting saw blade0-45°
Main motor4kw
Scoring saw blade120mm
Speed of scoring saw8000r/min
Spindle of scoring saw20mm
Auxiliary motor power0.75kw
Lifted by electric moter25kw
MOULDER
Arbor dia.φ30mm
Arbor useful height85mm
Arbor speed1750r/min or 3500r/min or 6700r/min
Use moulder hood
Cutter rotating Max. dia.φ180mm
Use shaping hood
Cutter rotating Max. dia.φ140mm
Motor power2.2kw
Net weight740kg
Gross weight(wooden packing case)870kg
Packing case2200×1170×1100 mm





Precision Panel Saw Machine with Saw and Moulder SHM6132-TZ.GB with Dimensions sliding table 3200x380mm Precision Panel Saw Machine with Saw and Moulder SHM6132-TZ.GB with Dimensions sliding table 3200x380mmPrecision Panel Saw Machine with Saw and Moulder SHM6132-TZ.GB with Dimensions sliding table 3200x380mmPrecision Panel Saw Machine with Saw and Moulder SHM6132-TZ.GB with Dimensions sliding table 3200x380mm
