Precision Panel Saw Machine ML4520 With Max Sawing Length 2250mm and Max Sawing Thickness 80mm
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New, New
Place of Origin:
Shandong, China
Brand Name:
SHOOT
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Precision Panel Saw Machine MJ12-1600 With Major Table Size 385x800 mm and Sliding Panel Size 1600x270 mmNegotiableMOQ: 1 Piece -
Precision Panel Saw Machine MJ12-2000 With Major Table Size 385x800 mm and Sliding Panel Size 1600x270 mmNegotiableMOQ: 1 Piece
-
Precision Panel Saw Machine MJ12-2600 With Major Table Size 385x800 mm and Sliding Panel Size 1600x270 mmNegotiableMOQ: 1 Piece
-
Precision Panel Saw Machine MJ12-2800 With Major Table Size 385x800 mm and 90degree Tilting and Main Blade Speed 4000 RpmNegotiableMOQ: 1 Piece
-
Precision Panel Saw Machine MJ12-3200 With Major Table Size 385x800 mm and Rear Extension Table Size 310x500 mmNegotiableMOQ: 1 Piece
Place of Origin
Shandong, China
Brand Name
SHOOT
Model Number
ML4520
| Precision Panel Saw Machine | |
| Model: ML4520 | |
| max sawing length | 2250mm |
| max sawing thickness | 80mm |
| main saw motor power | 3kw |
| main spindle speed | 4000r/min |
| main spindle dia | 30mm |
| main saw blade dia | 300mm |
| saw blade tilt angle | 45-90 degree |
| scroing saw speed | 8850 r/min |
| scoring saw blade dia | 20mm |
| scoring saw blade dia | 100mm |
| milling spindle height | 120mm |
| milling spindle dia | 35 mm |
| milling spindle motor power | 3 kw |
| milling spindle speed | 3500 / 6000 / 8000/ 10000r/min |
| max planing width | 400mm |
| max planing depth | 5 mm |
| planing spindle speed | 5200 r/min |
| planing spindle diameter | 87 mm |
| planing motor power | 3 kw |
| planing thickness | 6-210mm |
| feed speed | 6 m/min 12 m/min |
| max mortise depth | 100mm |
| max mortise width | 16mm |
| table lengthways stroke | 105 mm |
| table transverse stoke | 160 mm |
| bit fitting diameter | 16mm |
| mortising table size | 470*230 mm |
| overall dimensions: | 2739*3636*1330 mm |
| net weight | 780 kgs |
