CNC Woodworking Router Machine SH-1325 With X Y Working Area 1300x2500mm
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
CNC or Not:
CNC
Place of Origin:
Shandong, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Allotypic Wood Engraver SH-2040 With X Y Working Area 2000X4000mm and Z Working Area 200mm and Table Size 2180X4500mmNegotiableMOQ: 1 Piece -
Double-head Laser Cutting Machine SH1326T With The Machine Possesses the Function of Cutting,engraving,scanning on Large ScaleNegotiableMOQ: 1 Piece
-
CNC Router Machine SH25-X With X Y Working Area 1300x2500mm and Z Working Area 200mmNegotiableMOQ: 1 Piece
-
Standard Wood Engraver SH-M25B With X Y Working Area 1300X2500mm and Z Working Area 200mm and Table Size 1480X3000mmNegotiableMOQ: 1 Piece
-
Wood Engraver For Export SH-M25X With X Y Working Area 1300X2500mm and Z Working Area 200mm and Table Size 1480X3000mmNegotiableMOQ: 1 Piece
Condition
New
CNC or Not
CNC
Place of Origin
Shandong, China
Brand Name
SHOOT
Model Number
SH-1325
Voltage
380V
Power(W)
1840W
Dimension(L*W*H)
3300 x 2150 x 1850mm
Weight
1400/1720kg
Certification
CE
| High speed style . Adopt whole steel structure , high speed gear wheel and Italy water cooling spindle. | |
| Wood working area : waving board , cabinet door , solid wood door , craft wood door , no-paint door , folding screen , craft window ,shoe polisher , game machine cabinet , Ma-jiang Table , computer table and panel type funiture . | |
| Advertising Area : making advertising products made from Brand Board , Acryl cutting , mould and some other material . | |
| Mould Area : Metal mould eg :engraving copper , aluminium and iron, and nonmetal mould eg scagliola ,sandstone , plastic board , PVC pipe , wood sheet etc . | |
| Other area : art and craft area , embossment and engraving photo. | |
| Feature: | |
| 1. It adopts ceremic bearing spindle, this spindle has high precision, long life time, low noise, small quiver, good parallel. | |
| 2. The whole steel structure , well welded , no distortion for whole structure . | |
| 3. Adopt imported square orbit , double slippers . Bearing heavy , working steadily , high precision , and long life time . | |
| 4. DSP controller system with USB interface , working without connecting with computer during working and easy to control . | |
| 5. Software : CAD / DAM designing software eg Type 3 / ArtCAM / Castmate / Wentai etc. | |
| 6. Vacuum Table with 6 vacuum zones, which can adsorb different sizes materials. Options for vacuum pump : Vacuum pump made in China or No-oil vacuum pump made in Germany . | |
| 7. Auto Oilling system. Easy to operate by pressing one key . | |
| 8. Adopt high speed stepper motor and drivers, and two motors for Y axis . Max speed is 35M/MIN . | |
| 9. Auto Aligning System . | |
| 10. Temperature Control System . Can prolong the life time of the spindle . | |
| CNC Woodworking Router Machine | |
| Model | SH-1325 |
| X Y working area | 1300x2500mm |
| Z working area | 250mm |
| Table size | 1680x3000mm |
| Max feeding | <20m/min |
| Working-holding | Option Vacuum system |
| Processor | DSP/100MHZ |
| Interface | USB |
| Command | G Code*.u00*.mmg*plt |
| Surroundings for software | DSP |
| Power (not include the spindle) | 1840W |
| Power | 220V50Hz |
| Main axle power rate | 4.5(Water cooling) |
| Main axle rotating | 0-24000rpm/min |
| Packing size | 3300 x 2150 x 1850mm |
| N.W./G.W. | 1400/1720kg |
| Work mode | Stepper |
| Dust collector | Single bag |
| Rotary device | 150mm |
| Set bits for cutting,engraving | |
