Home > Products > CNC Router Machine > CNC Woodworking Router Machine S1530 With X Y Working Area 1500x3000mm and Z Working Area 200mm
CNC Woodworking Router Machine S1530 With X Y Working Area 1500x3000mm and Z Working Area 200mm
Negotiable
/ Piece
1 Piece(Min. Order)
- Qingdao Port
- T/T Money Gram
You May Like
-
CNC Large Scale Router Machine CNCM40 With XY Working Area 2000x4000mm and Z Working Area >200mm
-
Stone Series CNC Router 1212 With XY Working Area 1200x1200mm and Z Working Area >100mm
-
CNC Large Scale Router Machine CNCM30 With XY Working Area 1500x3000mm and Z Working Area >200mm
-
CNC Marble Router Machine CNC-9015 With Table Size 1080x2000mm and Max Running Speed 5m/min
-
Cylinder Craft Wood Engraver SH-1200Y With XY Working Area 1200x200mm and Z Working Area 200mm
-
Double Heads CNC Router Machine CNC-8090 With XY Working Area 350x900mm and Z Working Area 120mm
Product Details
| Condition | New | Place of Origin | Shandong, China | |
| Brand Name | SHOOT | Model Number | S1530 |
Product Description
| High speed style . Adopt whole steel structure , high speed gear wheel and Italy water cooling spindle. | |
| Wood working area : waving board , cabinet door , solid wood door , craft wood door , no-paint door , folding screen , craft window ,shoe polisher , game machine cabinet , Ma-jiang Table , computer table and panel type funiture . | |
| Advertising Area : making advertising products made from Brand Board , Acryl cutting , mould and some other material . | |
| Mould Area : Metal mould eg :engraving copper , aluminium and iron, and nonmetal mould eg scagliola ,sandstone , plastic board , PVC pipe , wood sheet etc . | |
| Other area : art and craft area , embossment and engraving photo. | |
| Feature: | |
| 1. It adopts ceremic bearing spindle, this spindle has high precision, long life time, low noise, small quiver, good parallel. | |
| 2. The whole steel structure , well welded , no distortion for whole structure . | |
| 3. Adopt imported square orbit , double slippers . Bearing heavy , working steadily , high precision , and long life time . | |
| 4. DSP controller system with USB interface , working without connecting with computer during working and easy to control . | |
| 5. Software : CAD / DAM designing software eg Type 3 / ArtCAM / Castmate / Wentai etc. | |
| 6. Vacuum Table with 6 vacuum zones, which can adsorb different sizes materials. Options for vacuum pump : Vacuum pump made in China or No-oil vacuum pump made in Germany . | |
| 7. Auto Oilling system. Easy to operate by pressing one key . | |
| 8. Adopt high speed stepper motor and drivers, and two motors for Y axis . Max speed is 35M/MIN . | |
| 9. Auto Aligning System . | |
| 10.Temperature Control System . Can prolong the life time of the spindle . | |
| CNC Woodworking Router Machine | |
| Model | S1530 |
| X Y working area | 1500x3000mm |
| Z working area | 200mm |
| Table size | 1680x3500mm |
| Max feeding | <25m/min |
| Working-holding | Vacuum system |
| Processor | DSP/100MHZ |
| Interface | USB |
| Command | G Code*.u00*.mmg*plt |
| Surroundings for software | DSP |
| Power (not include the spindle) | 2500W |
| Power | 380V50Hz |
| Main axle power rate | 4.5KW(Water cooling) |
| Main axle rotating | 0-18000rpm/min |
| Work mode | Stepper |
