CNC Woodworking Router Machine SHCNCD-2040 With X Y Working Area 2000x4000mm and Z Working Area 200mm
Negotiable
/ Piece
1 Piece(Min. Order)
- Qingdao Port
- T/T Money Gram
You May Like
-
CNC Router Three-head Machine SH1325TS With Travelling Area 1260x2500mm and Working Area 1240x2480mm and Table Size 1300x2500mm
-
CNC Router Machine SHFDP1335 With Working Table 1300x2000x800mm and Max. Working Dia. 800mm
-
CNC Automatic Loading And Unloading Router SHD-1325 With Travelling Size 2500*1260*200mm and Working Size 2440*1240*50mm
-
CNC Automatic Drilling Center SH-1330-PTP With Travelling Size 3400*1640*250mm and Working Size 3060*1260*200mm
-
CNC Cutting and Drilling Machine SH-H5 With XY Working Area 1250x2440mm and Z Working Area >110mm
-
CNC Cutting and Drilling Machine SH-H6 With XY Working Area 1250x2440mm and Z Working Area >110mm
Product Details
| Condition | New | CNC or Not | CNC | |
| Place of Origin | Shandong, China | Brand Name | SHOOT | |
| Model Number | SHCNCD-2040 | Voltage | 380V | |
| Power(W) | 4.5KW | Dimension(L*W*H) | 5000x2250x1800mm | |
| Weight | 2000kg | Certification | CE |
Product Description
| CNC Woodworking Router Machine | |
| High speed style . Adopt whole steel structure , high speed gear wheel and Italy water cooling spindle. | |
| Wood working area : waving board , cabinet door , solid wood door , craft wood door , no-paint door , folding screen , craft window ,shoe polisher , game machine cabinet , Ma-jiang Table , computer table and panel type funiture . | |
| Advertising Area : making advertising products made from Brand Board , Acryl cutting , mould and some other material . | |
| Mould Area : Metal mould eg :engraving copper , aluminium and iron, and nonmetal mould eg scagliola ,sandstone , plastic board , PVC pipe , wood sheet etc . | |
| Other area : art and craft area , embossment and engraving photo. | |
| Feature: | |
| 1, It adopts ceremic bearing spindle, this spindle has high precision, long life time, low noise, small quiver, good parallel. | |
| 2, The whole steel structure , well welded , no distortion for whole structure . | |
| 3, Adopt imported square orbit , double slippers . Bearing heavy , working steadily , high precision , and long life time . | |
| 4, DSP controller system with USB interface , working without connecting with computer during working and easy to control . | |
| 5, Software : CAD / DAM designing software eg Type 3 / ArtCAM / Castmate / Wentai etc. | |
| 6, Vacuum Table with 6 vacuum zones, which can adsorb different sizes materials. Options for vacuum pump : Vacuum pump made in China or No-oil vacuum pump made in Germany . | |
| 7, Auto Oilling system. Easy to operate by pressing one key . | |
| 8, Adopt high speed stepper motor and drivers, and two motors for Y axis . Max speed is 35M/MIN . | |
| 9, Auto Aligning System . | |
| 10, Temperature Control System . Can prolong the life time of the spindle . | |
| MODEL | SHCNCD-2040 |
| X Y working area | 2000x4000mm |
| Z working area | 200mm |
| Table size | 2380x4500mm |
| Max feeding | <20m/min |
| Working-holding | Vacuum system |
| Processor | DSP/100MHZ |
| Interface | USB |
| Command | G Code*.u00*.mmg*plt |
| Surroundings for software | DSP |
| Power (not include the spindle) | 1840W |
| Power | 380V50Hz |
| Main axle power rate | 4.5KW |
| Main axle rotating | 0-24000rpm/min |
| Work mode | Stepper |
| Rotary working table | with 3D rotary working table |
| Weight | 2000kgs |
| Packing Size | 5000x2250x1800m |
