Home > Products > CNC Router Machine > CNC Styrofoam Machining Center SH-1224MC with X Y working size 1200x2400mm and Z working size 500mm
CNC Styrofoam Machining Center SH-1224MC with X Y working size 1200x2400mm and Z working size 500mm
Negotiable
/ Piece
1 Piece(Min.Order)
- 100 Piece / Pieces per Month
- Qingdao Port
- T/T
You May Like
-
engraving cnc router,1325 woodworking cnc router 1300*2500*200
-
engraving and milling machine,1325 woodworking cnc router 1300*2500*200
-
engraver router,1325 woodworking cnc router 1300*2500*200
-
dsp control cnc machine,1325 woodworking cnc router 1300*2500*200
-
cnc woodworking router machine,1325 woodworking cnc router 1300*2500*200
-
cnc woodworking router,1325 woodworking cnc router 1300*2500*200
Product Details
| Condition: | New | CNC or Not: | CNC | Place of Origin: | Shandong, China |
| Brand Name: | SHOOT | Model Number: | SH-1224MC | Voltage: | AC380V |
| Power(W): | 7.5KW | Certification: | CE |
Product Description
| CNC Styrofoam Machining Center | |
| Feature | |
| Adopt Shanghai Ncstudio control system, high precision, fast speed. German transmission system, Italy imported spindle. | |
| Imported four-row ball bearing, linear guide widening, self-lubricating block to make equal force in all directions to ensure the mechanical accuracy and strength. | |
| Z axis can be up to 1m, can work for materials which are big and thick. | |
| Intelligent processing cross-border protection, to prevent the mechanical impact due to excessive design documents processing. | |
| Mold industry: Foundry industry, Automotive industry, Wind Power, steamboat & yacht, Aerospace Chemical, Rail transport. | |
| Musical instruments: Large-scale three-dimensional surface instruments, Overall cutting. | |
| Application: Styrofoam foam (EPS), plaster, wood and nonmetal (Mixed carbide material). | |
| Model | SH-1224MC |
| X Y working size | 1200x2400mm |
| Z working size | 500mm |
| Table size | 1380x2900mm |
| Operating system | Shanghai Weihong genuine control system |
| Spindle | 7.5KW air-cooled spindle |
| Spindle speed | 100-10000r / min |
| Operating mode | Japan Yaskawa servo motor 1000W |
| Drive | Japan Yaskawa servo drive |
| Transmission | X Y rack Z screw |
| Rail | Taiwan 20 square track |
| Accuracy | Diagonal accuracy of 0.05mm, repeat the positioning accuracy of 0.0254mm |
| Working voltage | AC380V / 50HZ |
| Run command | G code, F / S command compatible |
| Tool holder | max 20 |
Contact Us
- Yantai Shoot Import & Export Co., Ltd.
- Contact nameQu Jun
- Phone86-535-8949911,4222377
- AddressNo.113,Zhengfu Street,Muping District,Yantai City,Shandong,China Yantai,Shandong
