Digital Display Jig Grinder MGX2945B With Table Size 450X800mm
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
SHOOT
Model Number:
MGX2945B
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Saw Line Machine SH2680B With Max. Width 150mm and Max. Teeth Space 35mmNegotiableMOQ: 20 Pieces -
Gear Grinding Machine SH1116 With Max. Width 150mm and Max. Teeth Space 35mmNegotiableMOQ: 5 Pieces
-
Blade Griding Machine JMY8-70 With Specification 125 x 10 x 32 x 8 mmNegotiableMOQ: 20 Pieces
-
Blade Grinder SHY8-70 With Stipulation 125x10x32x8mm and Diameter of Grindable Saw 80-700mmNegotiableMOQ: 20 Pieces
-
6" Grinder Sander w/ Light SHBGL650 With Working Parts Size 150x20mm,6" x 3/4"/50x686mm,2"x27"NegotiableMOQ: 50 Pieces
Place of Origin
Shandong, China
Brand Name
SHOOT
Model Number
MGX2945B
Power Source
Electricity
Type
Other, Other, Other
Variable Speed
No
Disc Diameter
100mm
Disc(Wheel) Type
Grinding Disc
| Digital display jig grinder | ||
| MODEL | MGX2945B | |
| table size | 450X800mm | |
| table travel (X,Y) | 400X600mm | |
| table feedrate | 1000mm/min | |
| max.load capacity of worktable | 300kg | |
| wheel stroke | 100mm | |
| max. stroke speed for the wheel | 1800mm/min | |
| stroke frequency for grinding wheel(above 25mm) | - | |
| distance from planet spindle center to column guideway's top surface | 474mm | |
| C-axis speed | - | |
| wheel speed | electric | 45000rpm |
| pneumatic | 180000rpm | |
| max. grinding dia. for planet grinding | φ250mm | |
| max.hole taper | 12° | |
| radial feed level | manual | 4.5mm |
| CNC control | - | |
| positioning accuracy | 0.003mm | |
| repeatability(R) | - | |
| reverse quantity difference | - | |
| machining accuracy | 0.005mm | |
| roundness of planet hole | 0.002mm | |
| roundness of arc interpolation hole | - | |
