ZL15F Wheel Loader With Joystick
- Qingdao
- T/T
You May Like
Product Details
| Condition | New | Brand Name | HUIZHONG | |
| Model Number | ZL15F | Place of Origin | Shandong, China | |
| Type | Front Loader | Moving Type | Wheel Loader | |
| Dimension(Long * Breadth * High) | 4760X1680X2550 | Rated Load | 1500KG |
Product Description
Specifications
CE wheel loader*EURO III approved diesel engine
*Joystick
*various optional tools
*New fashion adjustable seat,wide tyres
ZL15F wheel loader
Specification | overall weight(kg) | 3600 |
L×W×H(mm) | 4760×1680×2550 | |
rated bucket capacity(m3) | 0.7 | |
Rated load(kg) | 1500 | |
Maximum dump height (mm) | 2750 | |
Bucket indicator | Yes | |
Max. breakout force(KN) | 43 | |
Engine | Model | Xinchai498(EURO III) |
Type | In-line arrangement, Water cooling, four-stroke | |
Rated power(kw) |
36.8kw | |
Rated speed(r/min) | 2200 | |
Transmission system | Model of torque converter | YJ240 |
Type | single-phase single-stage radial-inward turbine triplex | |
Gearbox type | Fixed-spindle power shift | |
Gear shift | 2 gears ahead,2 gear astern | |
Hydraulic system | Distribution of work valve | ZL20B |
Working pump | CBGj1045,CBGq1018 | |
Steering system | Type | Articulated hydraulic steering |
Max. turning angle | 27±1° | |
Min turning radius(mm) | 3000 | |
Brake system | Brake type | Oil brake(Vacuum booster) |
Tyres | Standard tyres | 12-16.5 |
Optional wide tyres | 14-17.5 |
