China 3t Exported to Saudi Arabia / Iraq / Turkey Front Loader With EPA Engine to Canada

Qingzhou Huizhong Machinery Co., Ltd.
China 3t Exported to Saudi Arabia / Iraq / Turkey Front Loader With EPA Engine to Canada thumbnail-1
China 3t Exported to Saudi Arabia / Iraq / Turkey Front Loader With EPA Engine to Canada thumbnail-2
China 3t Exported to Saudi Arabia / Iraq / Turkey Front Loader With EPA Engine to Canada thumbnail-3
China 3t Exported to Saudi Arabia / Iraq / Turkey Front Loader With EPA Engine to Canada thumbnail-4
China 3t Exported to Saudi Arabia / Iraq / Turkey Front Loader With EPA Engine to Canada photo-1
China 3t Exported to Saudi Arabia / Iraq / Turkey Front Loader With EPA Engine to Canada photo-2
China 3t Exported to Saudi Arabia / Iraq / Turkey Front Loader With EPA Engine to Canada photo-3
China 3t Exported to Saudi Arabia / Iraq / Turkey Front Loader With EPA Engine to Canada photo-4
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Brand Name:
HUIZHONG
Model Number:
ZL936
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Brand Name HUIZHONG
Model Number ZL936
Place of Origin Shandong, China
Type Front Loader
Moving Type Wheel Loader
Dimension(Long * Breadth * High) 7050X2430X3120mm
Rated Load 3000kg
Certification CE ISO9001:2008, CE
Warranty 12 Months
After-sales Service Provided Engineers available to service machinery overseas

Specifications

*CE/ISO9001:2008 wheel loader with Deutz/cummins engine
*WEICHAI Engine or Cummins engine
*Floating position valve

Specifications of JN936  front loader

Specification

overall weight(kg)

9500

L×W×H(mm)

7050×2430X3120

rated bucket capacity(m3)

1.7

Rated load(kg)

3000

Maximum dump height (mm)

3020/3250

Bucket indicator

Yes

Max. breakout force(KN)

138

Engine

Model

       WEICHAI Deutz TD226B/Cummins 6BT5.9-C125

Type

In line,direct injection,four-stroke,liquid cooled



Rated power(kw)



92kw

Rated speed(r/min)

2200

Transmission    system

Model of torque converter

YJ320B

Type

single-phase single-stage radial-inward turbine triplex

Gearbox type

Fixed-spindle power shift

Gear shift

2 gears ahead,2 gear astern

  Hydraulic system

Distribution of work valve

DF25

Working pump

CBGj2100,CBGq2100

   Steering system

Type

Articulated hydraulic steering

Max. turning angle

                               lift and right 36.5±1°

Min turning radius(mm)

5862

    Brake system

Brake type

air-break brake

          Tyres

Standard tyres

17.5-25





Why choice this wheel loader and our factory :



1. JN936 wheel loader with Xinchai 4 cylinders EURO III and EPA III approved



    Diesel engine;



2. JN936 wheel loader with Floating position valve ,could avoid unnecessary hurts



    From Hard stone .



3. JN936 wheel loader with Lock on lift arms and steering cylinders ,could avoid



    Stealed .



4. JN936 with good control system -- Hydraulic Joystick and Quick hitch could save



    Work time ,also could get more efficiency .



A: We have many years export experience ,could come over different difficults on



    Custome .



B: We specialized in wheel loader and metal parts produce ,have the whole



    assembly line to produce wheel loader .



C: Our Market spread all over the world ,could make changes for different areas .





D: We have the foreign engineers to design the wheel loader for our market ,could



     Follow the worlds' Change .
