Various optional tools JN920 high quality wheel loader with CE
- 1000 Piece / Pieces per Month
- Qingdao
- T/T
You May Like
-
HZM930 wheel loader manufacturer for BULL loader NEO loader
-
new design popular cleaning snow chinese wheel loader ZL933/HZM 933 wheel loader with DEUTZ engine in Russia
-
ZL932 best price with top quality front end loader EPA engine
-
ZL932 best price with top quality front end loader sale with Fork
-
ZL932 best price with top quality front end loader 3 ton
-
ZL930 best offer with top quality wheel loader for sale with pallet fork
Product Details
Condition | New | Brand Name | HUIZHONG | |
Model Number | JN920 | Place of Origin | Shandong, China | |
Type | Front Loader | Moving Type | Wheel Loader | |
Dimension(Long * Breadth * High) | 5950x1900x2850 | Rated Load | 2000kg | |
Certification | CE | Warranty | 1year |
Product Description
Specifications
CE wheel loader with construction machinery*Hydraulic quick change
*Various optional tools:pallet fork
JN920 shovel loader
Specification | overall weight(kg) | 5500 |
L×W×H(mm) | 5950×1900×2850 | |
rated bucket capacity(m3) | 1.0 | |
Rated load(kg) | 2000 | |
Maximum dump height (mm) | 2850 | |
Wheelbase | 2330mm | |
thread | 1460mm | |
Max breakout force | 70KN | |
Total time | 11.3s | |
Bucket indicator | Yes | |
Engine | Model | YTR4108G92 |
optional | Cummins4BT3.9-C100 | |
Type | Vertical, In-line , Water cooling, four-stroke diesel engine | |
Rated power(kw) | 60KW/75kw | |
Rated speed(r/min) | 2400 | |
Transmission system | Model of torque converter | YJ280 |
pattern | 3 element single stage | |
Gearbox type | Fixed-spindle power shift | |
Gear shift | 2 gears ahead,2 gear astern | |
Max travel speed | 24km/h | |
Hydraulic system | Working pump | CBF25 |
DISPLACEMENT | 25ml/r | |
Working pressure | 16Mpa | |
Distribution valve | DF20.2C | |
Axle | Main reducer pattern | Arc taper gear, moderation of first grade |
Pattern of wheel reduction | Planet gear moderation of single | |
Steering system | Type | hydraulic steering |
Min turning radius(mm) | 4500 | |
Max turning angle | 35°±1 | |
Tires | Standard tyres | 16/70-20 |
Break system | Service brake type | Air assisted oil disc on four wheel |
Parking brake type | Soft axle control, outside bunch drum type |
