QINGZHOU HUIZHONG MACHINERY CO.,LTD
We are a factory,specalized in producing wheel loader,
have "HZM series""JN series""NEO series".
or you had seen our loaders.we are the real manufacturer,and the sole.if need anything about wheel loader,contact us and welcome to our factory to test.
HZM908 WHEEL LOADER
Specification |
overall weight(kg) |
2500 |
L×W×H(mm) |
4200×1600×2550 |
|
rated bucket capacity(m3) |
0.3 |
|
Rated load(kg) |
800 |
|
Maximum dump height (mm) |
2750 |
|
Bucket indicator |
Yes |
|
Max. breakout force(KN) |
43 |
|
Engine |
Model |
Changchai 385 |
Type |
In-line arrangement,Water cooling, four-stroke |
|
|
Rated power(kw) |
20KW |
|
Rated speed(r/min) |
2200 |
|
Transmission system |
Model of torque converter |
YJ240 |
Type |
single-phase single-stage radial-inward turbine triplex |
|
Gearbox type |
Fixed-spindle power shift |
|
Gear shift |
2 gears ahead,2 gear astern |
|
Hydraulic system |
Distribution of work valve |
ZL20B |
Working pump |
CBGj1045,CBGq1018 |
|
Steering system |
Type |
Articulated hydraulic steering |
Max. turning angle |
27±1° |
|
Min turning radius(mm) |
3000 |
|
Brake system |
Brake type |
Oil brake(Vacuum booster) |
Tyres |
Standard tyres |
750-16 |
Optional wide tyres |
10-16.5/31*15.5-15 |
standard equipments
*hydrostatic 4 wheel drive
*CHANGCHAI 385 engine
*standard bucket with teeth
*bigger space cabin
*3-way joystick for operating easily
*hydraulic quick-hitch for attachments
*heater in cabin
*water and air preheater
*comfortable seat
*front and rear headlight
*LED light
*tool box (include tool kit and lever grease gun)
hydrostatic system(new and bigger cabhin,widder tire 31*15.5-15,LED light,new shape)
changchai 385 engine(3 cylinders)
electronic control system+quick hitch+comfortable seat+adjustable steering wheel+float function
1 unit for 20ft container,3-4 units for 40HC
you can find other model loader in our factory.
