SH-02V-S-B High Frequency Housing

Specifications

Specifications :
Current Rating : 1A AC,DC
Voltage Rating : 50V AC,DC
Temperature Range : -25 deg C ~+85 deg C
Contact Resistance : 20m Omega Max.
Insulation Resistance : 100M Omega Min.
Withstanding Voltage : 500V AC/minute
*Contact YXS for detals*"

Housing
part No:YXS1001H-
poles:2-20P
Material:PBT+15% Glass Fiber UL94V-0
Packing Q'TY:1000pcs/bag
Mates With YXS1001WV- Series Single Row Wafer

Terminal

Part No:YXS1001-T
Thickness:0.15mm
Material:Phosphor bronze
Finish:Tin Plated
Wire Range:AWG#28-#32
Insulation O.D. : 0.8mm
Q'TY:20,000pcs/reel
Mates With YXS1001H- Series Housing

Wafer
part No:YXS1001WV/WR-S-1*NP / 2*NP
poles:2-20P
Material:Nylon46 UL94V-0
Packing Q'TY:1000pcs/bag
Mates With YXS1001H-1*NP Series Single Row Housing
Mates with YXS1001H-2*NP Series Dual Row Housing.
