YXS2544 2-16P 2.54mm write to board connector

Specifications

Specifications :
Current Rating : 3A AC,DC
Voltage Rating : 250V AC,DC
Temperature Range : -25 deg C ~+85 deg C
Contact Resistance : 20m Omega Max.
Insulation Resistance : 1000M Omega Min.
Withstanding Voltage : 1000V AC/minute
*Contact YXS2544 for detals*

Housing
Part No:YXS2544H-
Poles:2-12P.
Material:Nylon66 UL94V2
Packing Q'TY:1000pcs/bag
Mates WithYXS2544T  Series Terminal

Terminal
Part No:YXS2544T
Thickness:0.20mm
Material:Phosphor bronze/ Brass
Finish:Tin Plated
Wire Range:AWG#22-#30
Insulation O.D. : 1.40mm ( Max.)
Q'TY:10,000pcs/reel
Mates With YXS2544H- Series Housing

Wafer (DIP  Type)
Part No:YXS2544WV/WR-NP
Poles:2-12P
Material:Nylon66 UL94V-0
Packing Q'TY:1000pcs/box
Mates With YXS2544H- Series Single Row Housing
