YXS HRS DF13 tin terminal connection LF
- 10000 Set / Sets per Month
- shenzhen
- Credit Card
You May Like
Product Details
Brand Name | YXS | Model Number | SCT1252-T | |
Type | Other, Slabs line | Application | PCB | |
Gender | Other, N/A |
Product Description
Specifications
YXS HRS DF13 tin terminal connection LFYXS1252 Series (HRS DF13-Pitch1.25 Wire to Board Connector )
"Specifications :
Current Rating : 1A AC,DC
Voltage Rating : 150V AC,DC
Temperature Range : -25 deg C ~+85 deg C
Contact Resistance : 30m Omega Max.
nsulation Resistance : 500M Omega Min.
Withstanding Voltage : 500V AC/minute
*ContactYXS for detals*"
Housing
part No:YXS1252H-
poles:2*5P-2*20P
Material:Nylon66 UL94V-0
Packing Q'TY:1000pcs/bag
Mates With YXS1252WV-S-2*NP Series Dual Row Wafer
Terminal
Part No:YXS1252-T
Thickness:0.15mm
Material:Phosphor bronze
Finish:Tin Plated
Wire Range:AWG#26-#30
Insulation O.D. : 1.0mm
Q'TY:15,000pcs/reel
Mates With YXS1252H- Series Housing
Wafer
Part No:YXS1252WV-S-2*NP
Poles:2*5P-2*20P
Material:Nylon46 /6T UL94V-0
Packing Q'TY:1000pcs/box
Mates With YXS1252H- Series Dual Row Housing
