For YXS,1.5mm 4Pin 90Degree WFCurved needle holder Low frequency

Specifications

For YXS,1.5mm 4Pin 90Degree WFCurved needle holder Low frequency

"Specifications :
urrent Rating : 1A AC,DC
Voltage Rating : 200V AC,DC
Temperature Range : -25 deg C ~+85 deg C
Contact Resistance : 20m Omega Max.
Insulation Resistance : 500M Omega Min.
Withstanding Voltage : 500V AC/minute
*Contact YXS1501 for detals*"

Housing
part No:YXS1501H-
poles:2-15P.
Material:Nylon66 UL94V-0
Packing Q'TY:1000pcs/bag
Mates With YXS1501T  Series Terminal

Terminal
Part No:YXS1501T
Thickness:0.20mm
Material:Phosphor bronze
Finish:Tin Plated
Wire Range:AWG#28-#30
Insulation O.D. : 1.0mm ( Max.)
Q'TY:15,000pcs/reel
Mates With YXS1501H- Series Housing

Wafer (DIP and SMT Type)
part No:YXS1501WV/WR-NP  or SCT1501WV/WR-S-NP
poles:2-15P
Material:Nylon6T UL94V-0
Packing Q'TY:1000pcs/box
Mates With YXS1501H- Series Single Row Housing
