YXS2003HR-02P 2.0mm write to board connector

Specifications

Current Rating: 2A AC, DC
Voltage Rating: 250V AC, DC
Temperature Range: -25 deg C ~ +85 deg C
Contact Resistance: 20m Omega Max.
Insulation Resistance: 1,000M Omega Min.
Withstanding Voltage: 800V AC/minute
Contact YXS for details.

B2011V-T ( Vertical Angle Crimp Terminal )
Wire Range : AWG#24~#30
Insulation O.D. : 1.30mm ( Max.)
Used in YXS B2011HV Series Housing

B2011R-T ( Right Angle Crimp Terminal )
Wire Range : AWG#24~#30
Insulation O.D. : 1.30mm ( Max.)
Used in YXS B2011HR Series Housing

"B2011HV-XP ( Vertical Angle Housing )
Suitable YXS B2011V Series Terminal

B2011HR-XP ( Right Angle Housing )
SuitableYXS. B2011R Series Terminal
