NAKIN Turbine Oil Purifier--Security Online with Gas turbine,Hydraulic Turbine
- 200 Set / Sets per Month
- Chongqing
- T/T
-
Waste Oil Regenerating Equipment for Various Dielectric Oils
-
BZ Transformer oil regeneration Equipment
-
Transformer OLTC On-load Tap Changer Oil Purifier//separator/Regeneration/Dehydration Machine
-
Insulation Oil Regeneration Machine
-
On-load Tap Changer Oil Filter Oil Filtration Machine Oil Decanter
-
Specilize Model BZ Transformer Oil Regeneration Unit
Product Details
| Condition: | New | Flow: | 600~18000 liters per hour | Working Pressure: | <=0.4MPa |
| Place of Origin: | Chongqing, China | Brand Name: | NAKIN | Model Number: | TY |
| Usage: | Other, turbine oil | Certification: | CE |
Product Description
NAKIN Turbine Oil Purifier--Security Online with Gas turbine,Hydraulic Turbine
Series TY Turbine oil purifier Application:
Series TY vacuum turbine oil purifier mainly be used for purifying unqualified turbine oil, especially for serious emulsion turbine oil. it can quickly and efficiently break emulsification, separate water, gas, particles from oil. So that makes sure quality of treated oil to achieve new oil’s standard, ensure whole turbine system work safely.
TY Vacuum turbine oil purifier use a special polymer materials as filter medium combined with vacuum separating technology to break emulsification, dewater, degas, remove acid and particles, make the badly turbid turbine oil becomes clear transparent.
Series TY is a perfect turbine oil purifier for live line work; also it can purify low viscosity hydraulic oil and lube oil.
Series TY Turbine oil purifier Features:
1. Special polymer materials as filter medium with the functions of broken emulsion, dewatering, removing particles
2. Duplex-Stereo film evaporation technology, equips with unique and advanced dewatering, degassing components, can rapidly and effectively separate water, gas from oil.
3. Multi-stage precision filtration system, mesh filtration combined with molecular adsorption technology.
4. Efficient electric heating system, heating uniformity, less power consumption, safe, and reliable.
5. Double-infrared liquid level sensor, pressure protective system to ensure machine operation easy and safely.
6. Adopt interlocked protective system, which connect oil pump, heater and liquid level sensor, avoiding blank heating, blank pumping, oil leak and electricity leak. If there is any fault, machine will be power off automatically.
7. Work online with stream turbine, hydraulic turbine.
Series TY Turbine oil purifier Technical Parameters:
Index Name | Unit | TY-10 | TY-20 | TY-30 | TY-50 | TY-100 | TY-150 | TY-200 | TY-300 |
Flow rate | L/H | 600 | 1200 | 1800 | 3000 | 6000 | 9000 | 12000 | 18000 |
Working vacuum | MPa | -0.06~-0.095 | |||||||
Working pressure | MPa | ≤ 0.4 | |||||||
Temperature range | °C | 20 ~80 | |||||||
Demulsifying value | min | ≤ 15/min(GB/F7035) | |||||||
Water content | ppm | ≤ 80 | |||||||
Gas content | % | ≤ 0.1 | |||||||
Cleanness |
| ≤ NAS 6 grade | |||||||
Power supply |
| 380V 50HZ 3Ph (As per user’s option) | |||||||
Working noise | dB(A) | ≤65~80 | |||||||
Heating power | Kw | 12 | 15 | 18 | 24 | 45 | 60 | 72 | 84 |
Total power | Kw | 14 | 17 | 20 | 27 | 48 | 66 | 81 | 97 |
Our products list as following:
1.Insulating oil purifier:
ZY Series: Vacuum insulation oil purifier
ZYD Series: Double-stage vacuum insulation oil purifier
ZYM Series: Mobile type transformer oil purifier
2.Turbine oil purifier:
TY Series: Vacuum turbine oil purifier
3.Lubricating oil purifier
TYA Series: Vacuum lubricating oil purifier
4.Vacuum engine oil purifier
5.Coalescence separation diesel oil, gasoline oil and fuel oil purifier
6.Water oil separator, oil purifier machine
7.Transformer oil regeneration device
8.Plate pressure oil purifier
9.Portable oil purifier
10.insulating oil dielectric strength tester
