Help CenterTY Vacuum Turbine Oil Processing Machine for Dehydration & Demulsification
Related Products
-
TY200 Portable Vacuum Turbine Oil Purifier DisposalUS$ 3,600 - 8,500MOQ: 1 Set -
TY200 Waterproof Vacuum Turbine Oil Purification DeviceUS$ 3,100 - 8,800MOQ: 1 Set
-
Vacuum Turbine Oil Purification Machine With Germany Leybold Vacuum PumpUS$ 3,500 - 17,000MOQ: 1 Set
-
Vacuum Turbine Oil CleanerUS$ 5,000 - 20,000MOQ: 1 Set
-
TY Model Turbine Oil Purification MachineUS$ 10,000 - 40,000MOQ: 1 Set
TY150 Vacuum Turbine Oil Filtration Machine for Dehydration & Demulsification
Application
This equipment use a special polymer materials as filter medium combined with vacuum separating technology to break emulsification, dewater, degas, remove acid and particles, make the badly turbid turbine oil becomes clear transparent.
It can quickly and efficiently break emulsification, separate water, gas, particles from oil. So that makes sure quality of treated oil to achieve new oil’s standard, ensure whole turbine system work safely.
Features:
- Special filter medium with the functions of broken emulsion, dewatering, removing particles
- Duplex-Stereo film evaporation technology, equips with unique and advanced dewatering, degassing components, can rapidly and effectively separate water, gas from oil.
- Multi-stage precision filtration system, mesh filtration combined with molecular adsorption technology.
- Efficient electric heating system, heating uniformity, less power consumption, safe, and reliable.
- Double-infrared liquid level sensor, pressure protective system to ensure machine operation easy and safely.
- Adopt interlocked protective system, If there is any fault, machine will be power off automatically.
- Work online with stream turbine, hydraulic turbine
Technical Parameters:
Index Name |
Unit |
TY-10 |
TY-20 |
TY-30 |
TY-50 |
TY-100 |
TY-150 |
TY-200 |
TY-300 |
Flow rate |
L/H |
600 |
1200 |
1800 |
3000 |
6000 |
9000 |
12000 |
18000 |
Working vacuum |
MPa |
-0.06~-0.095 |
|||||||
Working pressure |
MPa |
≤ 0.4 |
|||||||
Temperature range |
°C |
20 ~80 |
|||||||
Demulsifying value |
min |
≤ 15/min(GB/F7035) |
|||||||
Water content |
ppm |
≤ 80 |
|||||||
Gas content |
% |
≤ 0.1 |
|||||||
Cleanness |
|
≤ NAS 6 grade |
|||||||
Power supply |
|
380V 50HZ 3Ph (As per user’s option) |
|||||||
