High Precision And Breaking Emulsion Vacuum Oil Water Separator,Vacuum Dehydration System
Application:
Series TJ Coalescence-separation oil purifier adopts advanced polymer fibre as the filter medium combined with the special oil-water separating device to make TJ is good at breaking emulsion and filtering. It can effectively separate water from oil. Series TJ can work online with turbine system for breaking emulsion and filtering, also it can separate particles and mass water from light oil. Series TJ works without heating and vacuum source, less power consumption, low operation cost. Series TJ use of trolley structure, light weight, easy operation.
Technical Parameters:
Index name |
unit |
TJ-10 |
TJ-20 |
TJ-30 |
TJ-50 |
TJ-80 |
TJ-100 |
Flow rate |
L/H |
600 |
1200 |
1800 |
3000 |
4800 |
6000 |
Working pressure |
MPa |
≤ 0.3 |
|||||
Demulsifying value |
min |
≤15/min(GB/F7035) |
|||||
Water content |
ppm |
≤100 |
|||||
Cleanness |
|
≤ NAS 6 GRADE |
|||||
Power supplier |
|
380V 50HZ 3Ph(As per user’s option) |
|||||
Working noise |
dB(A) |
≤65~80 |
|||||
Total power |
Kw |
0.75 |
0.75 |
0.75 |
2.2 |
2.2 |
3 |
Weight |
kg |
80 |
90 |
105 |
135 |
150 |
185 |
Wooden case Suitable for sea transportation and air transportation
After-sales Service:
Free design of fixtures as customers required.
Free training for machines installation and operation of the staffs.
Engineer is available for local installation.
24 months warranty from the delivery time.
24 hours online service question and answer.
Engineers Overseas Aftersale Service are available.
All NAKIN manufactured machines will be guaranteed with spare parts and service for one year upon the receiving of shipment.
All our patent parts will be assured with old for new service in its entire life time free of charge.(User damaging is not included)
Nakin Electromechanical Co., Ltd is leading machinery manufacture, our products are mainly transformer oil purifier, turbine oil purifier, lube oil filtration, engine oil regeneration machine in high quality and competitive price. We has the strong technology and experience in the vacuum oil purifier developing, our machine have been exported to many countries, and service in many industries.
Our products lists:
High effective vacuum transformer oil purifier, oil filtration
Double stages insulating oil purifier,oil treatment,oil purification
Mobile/trailer type transformer oil treatment,oil filtration mnachine
Air dryer for dring electric equipments
Turbine oil purifier,oil treatment
Coalescence and separating oil filter,oil purifier machine
Lubricating oil purifier/hydraulic oil purification
Phosphate ester fire-resistant oil purifier, oil filtration machine
Engine oil regeneration system, waste oil recycling
Transformer oil regeneration device,oil pruifier
Plate pressure oil filter, oil purifier machine
Portable oil piurifier,oil filtering,oil filter
BDV oil tester,insulating oil dielectric strength tester
Oil moisture sensor,water content tester
Office:
Workshop & Warehouse:
How To Contact Us?
Contact person: jerrytan
Whatsapp:+8618223358936
Company Name: Chongqing Nakin Electromechanical Co., Ltd
Address: Luohuang Industrial Park Area B, Luohuang, Jiangjin, Chongqing, China
Tel: 0086-23-85575926 Fax: 0086-23-85575930
Skype:jerrytan54
If you want to know more details , please feel free to contact us
