Specifications
Transformer Oil Dehydration Machine:1.dewatering and degassing
2.removing the acetylene
3.small, light weight and convenient
Most Convenient Model Transformer Oil Dehydration Machine
Application:
Series JL portable oil purifier mainly deal with unqualified insulating oil, turbine oil, lubricating oil etc., this machine can do precision filtering, it usually equips three-stage filters, also can equip four or five stage filters as per user’s requirements . Light weight, easy operation, it can be used as oiling machine for long distance and high-lift oiling works.
Features:
1. Use patented technology to produce. Such as high-effective separating separation tower, fuzzy control technology, dewatering and degassing very effectively.
2. It can purify the losing-efficient insulation oil and make the oil reach the new oil standard without power cut, changing the oil or using filtering papers.
3. Have the function of filling oil under vacuum condition.
4. Solve the problem of removing the acetylene.
5. The purifier has large route, strong capability of holding dirt and can be used for a long time.
6. This machine is small, light weight and convenient.
7. The ultrasonic cleaning function can be selected.
8. Have the multi-functions of centrifugal separation, molecular filter, condension de-watering and vacuum dry.
9. Have the functions of automatic burning protection and elimination foam.
10. Operate steady and the noise is specially low.
Technical parameters:
Index name |
Unit |
JL-32 |
JL-50 |
JL-80 |
JL-150 |
JL-200 |
Flow rate |
m3/h |
1.9 |
3 |
6 |
9 |
12 |
Lift |
m |
5 |
8 |
8 |
10 |
15 |
Cleanness |
NAS |
7 |
6 |
6 |
6 |
6 |
Power |
KW |
0.75 |
0.75 |
2.2 |
3 |
4 |
Power supplier |
|
380V 50HZ 3Ph(As per user’s option) |
||||
Weight |
KG |
95 |
105 |
120 |
130 |
140 |
