PF Pressure Filter Waste Lube Oil Recovery Equipment
Application:
Series PF Plate-press oil purifier is mainly used to purify transformer oil, turbine oil, engine oil, diesel oil, aviation hydraulic oil etc. It can remove water and particles from oil, if adopting stainless steel body, the machine can be as the vegetable oil purifier. The machine is mainly composed of filtering bed, oil pump and primary-filtering components. It uses filter paper as filter medium, different filtration precisions choosing different filter paper. Series PF is high filtration precision, simple structure, easy operation, low operation cost.
Technical Parameters:
Index name |
Unit |
PF30 |
PF50 |
PF100 |
PF125 |
PF150 |
PF200 |
PF300 |
|
Flow rate |
L/H |
1800 |
3000 |
6000 |
7500 |
9000 |
12000 |
18000 |
|
Working pressure |
MPa |
0-0.3 |
|||||||
Filtering size |
≥ m 2 |
0.48 |
0.6 |
1.35 |
1.55 |
2 |
2.5 |
3.1 |
|
Plate dimension |
mm |
180×180 |
280×280 |
||||||
Pressing way |
Manual |
||||||||
Filter ring quantity |
14 |
18 |
39 |
47 |
24 |
29 |
34 |
||
Filter plate quantity |
15 |
19 |
40 |
48 |
25 |
30 |
35 |
||
Power |
KW |
1.1 |
2.2 |
3 |
5.5 |
||||
Inlet calibre |
1 |
1 1/4 |
2 1/2 |
||||||
Outlet calibre |
3/4 |
1 1/4 |
2 1/2 |
||||||
Dimension |
L |
mm |
800 |
900 1000 |
1100 |
1200 |
|||
W |
mm |
300 |
440 |
||||||
H |
mm |
720 |
840 |
1000 |
|||||
Filter paper |
mm |
180×180 |
280×280 |
||||||
Weight |
kg |
50 |
55 |
85 |
110 |
150 |
175 |
190 |
|
Particles size |
≤ 1-3 µm |
||||||||
Nakin Electromechanical Co., Ltd is leading machinery manufacture, our products are mainly transformer oil purifier, turbine oil purifier, lube oil filtration, engine oil regeneration machine in high quality and competitive price. We has the strong technology and experience in the vacuum oil purifier developing, our machine have been exported to many countries, and service in many industries.
NAKIN Company products list as following:
ZY-high effective vacuum transformer oil purifier, oil filtration
ZYD-Double stages insulating oil purifier, oil treatment, oil purification
ZYM-Mobile/trailer type transformer oil treatment, oil filtration machine
AD-Air dryer for drying electric equipments
TY-Turbine oil purifier, oil treatment
TJ-Coalescence and separating oil filter, oil purifier machine
TYA-Lubricating oil purifier/hydraulic oil purification
TYK- Phosphate ester fire-resistant oil purifier, oil filtration machine
JZS-Engine oil regeneration system, waste oil recycling
JYWL-Horizontal-closed type filtration device
TPF-Waste cooking oil recycling machine
BZ-Transformer oil regeneration device, oil purifier
PF-Plate pressure oil filter, oil purifier machine
JL-Portable oil purifier, oil filtering, oil filter
NKVW-Vacuum pump system
IIJ-II-BDV oil tester, insulating oil dielectric strength tester
NKEE-Oil moisture sensor, water content sensor
