Help CenterTYK Phosphate Ester Fire-resistant Oil Purifier, Vacuum Oil Purification, Oil Filtration
Related Products
-
High Effective Fire Resistant Oil Purifier/ Vacuum Oil FiltrationUS$ 1,000 - 5,000MOQ: 1 Set -
Machine Oil Purifier for Treating EH Oil , Fire Resistant OilUS$ 3,000 - 8,000MOQ: 1 Set
-
TYK-100 Vacuum Phosphate Ester Fire-resistant Oil Filter With Stainless Steel BodyUS$ 2,000 - 18,000MOQ: 1 Set
-
Vacuum TYK Series Phosphate Fire-resistant Oil Purifier , Waste Oil Refinery & Purification MachineUS$ 2,000 - 6,000MOQ: 1 Set
-
TYK-50 Vacuum Stainless Steel Fire-resistant Oil PurificationUS$ 2,000 - 18,000MOQ: 1 Set
Application:
Series TYK is latest model of vacuum oil purifier designed for purifying the unqualified phosphate ester fire-resistant oil, this machine can treat and regenerate the degenerative fire-resistant oil, removing acid, pigment, gas, water and particles. This machine body uses the special metal materials which are compatible with fire-resistant oil, combined with technologies of vacuum dewatering, multi-stage filtration system and new adsorbent to ensure treated oil achieve new fire-resistant oil properties. Series TYK is the necessary purifying equipment for the sectors which use fire-resistant oil, it can be online working and oil-filling.
Features:
1. Use of special metal materials which is compatible with fire-resistant oil, combined with technologies of vacuum dewatering, multi-stage filtration system and new adsorbent
2. Stainless steel machine body, pipes and filtering components, reliable, anti-corrosion, durable.
3. Duplex-Stereo film evaporation technology, equips with unique and advanced dewatering, degassing components, can rapidly and effectively remove water, gas, particles and volatile matter
4. Advanced medium cooling system
5. High quality filtering components, large capacity for holding particles, anti-corrosion, good mechanical performance, long lifetime.
6. Efficient electric heating system, heating uniformity, less power consumption, safe, and reliable.
7. Adopt interlocked protective system, which connect oil pump, heater and liquid level sensor, avoiding blank heating, blank pumping, oil leak and electricity leak. If there is any fault, machine will be power off automatically.
Technical Parameters:
Index name |
Unit |
TYK-10 |
TYK-20 |
TYK-30 |
TYK-50 |
TYK-100 |
Flow rate |
L/H |
600 |
1200 |
1800 |
3000 |
6000 |
Working vacuum |
MPa |
-0.06~-0.095 |
||||
Working pressure |
MPa |
≤0.3 |
||||
Demulsifying value |
min |
≤15/min(GB/F7035)+ |
||||
Water content |
ppm |
≤5 |
||||
Gas content |
% |
≤0.1% |
||||
Acid value |
mKOH/g |
≤0.05' |
||||
Resistance value |
Ω |
≤5.0×109Ω |
||||
Cleanness |
|
≤NAS 6 grade |
||||
Power supply |
|
380V 50HZ(As per user's option) |
||||
Working noise |
dB(A) |
≤65-80 |
||||
Temperature range |
C |
40-60 |
||||
Heating power |
Kw |
9 |
10 |
16 |
19 |
30 |
Our Main Series Products as following:
ZY-Single stage vacuum transformer oil purifier/oil filtration machine
ZYD-Double stages vacuum Transformer oil purifier/oil filtration machine
ZYM-Mobile type transformer oil purifier/oil filtration machine
AD-Air drying machine
TY-Vacuum Turbine oil purifier/oil filtration machine
TJ-Coalescence–Separating oil purifier/oil filtration machine
TYA-Vacuum Lubricating oil purifier/oil filtration machine
CXJ-Centrifugal oily water separating machine
JZS-Waste Engine oil regeneration machine
ZYS-On-load Tap Changer Oil Purifier
BZ-Transformer oil regeneration device
PF-Press paper oil filtration machine
JL-Portable oil oil purifier/oil filtration unit
BDV Dielectric oil’s breakdown voltage tester
NKEE-Transformer oil/lube oil moisture sensor
Oil purifier parts and various oil testing equipments (Oil Acid tester, oil viscosity tester)
Our Honor and Quality Certificate:
China Famous brand Oil Purifier Company
Golden-supplier for China National Electric power Group
Golden-Supplier for ALSTOM, SIEMENS, SCHNEIDER Company
ISO9001 products quality certificate
CE Products safety certificate
SGS Products local testing report
More than 10 years and 50 countries and districts exporting experience
Our After-sales:
Engineer is available for local installation.
24 months warranty from the delivery time.
24 hours online service question and answer.
More than 10 years experience
Packing and delivery way:
Wooden case Suitable for sea transportation and air transportation
