Application:
Special for testing the water content in the oil.
Series NKEE are specially designed for the measurement of water content in oil. Series NKEE is ideal for online monitoring of moisture in lubrication or insulation oil, which is very important for the long-term performance and adaptive maintenance of plant and machinery. For instance, moisture affects dramatically the insulation characteristics of electrical transformer oil and therefore continuous monitoring is extremely important.
Humidity measurement in oil:
Similar to the humidity in the air, the water content in an oil can be described by the absolute value in ppm or by the relative value aw: - ppm (mass of water / mass of oil) - aw (actual water content as fraction of the water content in the saturated oil) aw = 0 corresponds to water-free oil, while aw = 1 describes fully saturated oil. aw measurement with NKEE transmitter series is based on the outstanding long term stability and resistance to pollution of the NKEE capacitive sensor elements series HC.
Product Versions:
The physical quantities measured are water activity aw and temperature T. With these quantities NKEE calculates the water content (ppm) in mineral transformer oils. Calculation of water content in non-mineral transformer oils and lubrication oils can be accomplished by downloading specific parameters of the oil.
Technical Parameters:
Measuring range |
0...1 aw, -40...180C |
Output |
0-5V, 0-10V, 4-20mA, 0-20mA |
Acurracy |
+/- 0.01aw; +/- 0.2C |
Power supply |
24V AC/DC |
Nakin Electromechanical Co., Ltd is leading machinery manufacture, our products are mainly transformer oil purifier, turbine oil purifier, lube oil filtration, engine oil regeneration machine in high quality and competitive price. We has the strong technology and experience in the vacuum oil purifier developing, our machine have been exported to many countries, and service in many industries. Our products list as following:
ZYD-Double vacuum Transformer oil purifier
ZYM-Movable insulating oil purification cart
AD-Electric transformer air drying equipments
TY-Online Turbine oil treatment
TJ-Fuel oil filtration unit
TYA-Lubricating oil purifier/hydraulic oil purification
JZS-Engine oil regeneration system, waste oil recycling
BZ-Transformer oil regeneration device
PF-Press paper filter machine
JL-Portable oil piurifier,oil filtering,oil filter
BDV dielectric strength tester for transformer oil
NKEE-Oil moisture sensor
Vacuum oil purifier parts options:
Our company provide good quality machine with competitive price; machine warranty time is 18 months from the delivery date. We can make the specified machine as per user’s options:
1.Trailer type with fully closed for protecting oil purifier machine(Waterproof and dustproof)
2.Choosing different kinds vacuum pump, oil pump, and electric parts.
3.Explosion-proof (EX type) electric parts.
4.Equips moisture sensor and dielectric strength tester on the machine.
5.Filter elements for different requirements on filtering precision
6.Stainless steel material for oil purifier body.
7.Automatic PLC control system
We,Chongqing Nakin Electromechanical CO.Ltd, assure that all materials and equipment being finished under this proposal shall be new and free of defects in workmanship and materials, and shall be of the kind and quality specified in the technical specification. If the purchaser received the goods and discovers defects in workmanship or material and so on, pls notifies the supplier promptly in writing or call, we have the responsibility to provide the new one and technical supports in first time.
As our company dealer, we will provide professional technical learning and support to help this product dealer can better sales and service, to establish our company a good brand image. We invites interested parties to establish a long-term friendly cooperation.
Welcome to inquiry, we all are at your service!!!
