Product Details
| Condition | New | Flow | 600~ 6000 liters per hour | |
| Working Pressure | ≤ 0.3 MPa | Place of Origin | Chongqing, China | |
| Brand Name | NAKIN | Model Number | TJ | |
| Usage | Other, fuel oil | Certification | CE |
Product Description
TJ Light Fuel Oil Filter Separating Water Effectively
Application:
Series TJ Coalescence-separation oil purifier adopts advanced polymer fibre as the filter medium combined with the special oil-water separating device to make TJ is good at breaking emulsion and filtering. It can effectively separate water from oil. Series TJ can work online with turbine system for breaking emulsion and filtering, also it can separate particles and mass water from light oil. Series TJ works without heating and vacuum source, less power consumption, low operation cost. Series TJ use of trolley structure, light weight, easy operation
Technical Parameters:
Index name | unit | TJ-10 | TJ-20 | TJ-30 | TJ-50 | TJ-80 | TJ-100 | |
Flow rate | L/H | 600 | 1200 | 1800 | 3000 | 4800 | 6000 | |
Working pressure | MPa | ≤ 0.3 | ||||||
Demulsifying value | min | ≤15/min(GB/F7035) | ||||||
Water content | ppm | ≤100 | ||||||
Cleanness |
| ≤ NAS 6 GRADE | ||||||
Power supplier |
| 380V 50HZ 3Ph(As per user’s option) | ||||||
Working noise | dB(A) | ≤65~80 | ||||||
Total power | Kw | 0.75 | 0.75 | 0.75 | 2.2 | 2.2 | 3 | |
Weight | kg | 80 | 90 | 105 | 135 | 150 | 185 | |
Dimension | L | mm | 700 | 700 | 700 | 850 | 800 | 1000 |
W | mm | 570 | 570 | 600 | 650 | 650 | 700 | |
H | mm | 550 | 600 | 650 | 750 | 800 | 850 | |
