Cylinder Type Vertical Hydraulic Jack For Sale

Name: Cylinder Type Vertical Hydraulic Jack For Sale
Brand: China Coal
SKU: 143303658

US$ 30 - 500 MOQ: 1 Piece

Key Specifications

Place of Origin:

Shandong, China

Brand Name:

China Coal

Model Number:

RCH

Shandong China Coal Group Co., Ltd. Import &export Branch

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shandong, China

Brand Name China Coal

Model Number RCH

Type Hydraulic Jack

Certification ISO

Min Height 153mm

Max Height 260mm

Cylinder Type Vertical Hydraulic Jack For Sale Introduction

1. Steel base plate and saddle for protection the hollow piston and cylinder damage and increasing abrasion performance.

2. Dust ring stop the dust into cylinder during extension

3. Floating type plunger prevents the block caused by slight unbalance loading of piston

4.Step-limited piston prevents over-travel and is capable of stopping the spring compressed completely

5. Wear ring prevent metal to metal contact, increasing cylinder life and resistance to be scratched

6.High-efficient seal extends cylinder life

7.Handles included on all models

Item No.	RCH-2050	RCH-20100	RCH-3050	RCH-30100	RCH-6050	RCH-60100	RCH-10075
Output(T)	20	20	30	30	60	60	100
Stoke(mm)	50	100	50	100	50	100	75
Effective area(cm2)	22.9	22.9	36.29	36.29	67.89	67.89	94.98
Oil Capacity(L)	0.16	0.32	0.25	0.5	0.45	0.9	1.2
Height of products(mm)	153	217	153	217	164	231	254
Extended height(mm)	214	328	214	328	225	342	340
Outside(mm)	98	98	115	115	155	155	180
Bore die(mm)	73	73	88	88	125	125	140
Principal Dia(mm)	54	54	68	68	93	93	110
Thead for input oil-port(ZG)	27	27	34	34	54	54	79
Saddle protrusion form plgr(mm)	3/8"	3/8"	3/8"	3/8"	3/8"	3/8"	3/8"
Weight(kg)	7.2	10	10	13.4	17.2	23.2	41
