Machanized Belt End Stream Cutting Sampler

Machanized Belt End Stream Cutting Sampler thumbnail-1
Machanized Belt End Stream Cutting Sampler photo-1
US$ 1 - 9,999 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Jiangxi, China
Brand Name:
Guangming
Model Number:
GM/JCP-T
Contact Supplier Request Quote Chat Now
Jiangxi Guangming Intelligent Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai or Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Jiangxi, China
Brand Name Guangming
Model Number GM/JCP-T
Condition New

Specifications

Machanized Belt End Stream Cutting Sampler
1.GB/T475-2008 and GM/T10322.1-2000 standard
2.Cutting even sample
3.hgh effic

GM/JCP MACHENIZED BELT END STREAM CUTTING/CROSS BELT SAMPLER

TYPICAL APPLICATIONS

This equipment is mainly used for automatical sampling of sinter, pellet, ore powder, coal, coke and other solid material conveying by belt.



FEATURES

1. Belt width: 400-2000mm.

2. It cuts the complete cross-section of the stream at uniform speed, the samples are even.

3. The equipment is reliable and easy to be installed and operated.

4. It avoids the effect of the human factor to the material, which can make sure the sample is accurate with high representative and scientificity.

5. Both manual and automatic operation is available, which reduces the labor intensity and insures personnel safety.



GM/JCP-T MACHENIZED BELT END STREAM CUTTING SAMPLER

This sampler collects sample by cutting complete cross-section of the material stream at the discharge end of the belt, it consists of motor, reducer, cutter chute, approaching switch, steel frame and shield and so on.



GM/JCP-T MACHENIZED BELT END STREAM CUTTING SAMPLER

Sampling quantity

5~10kg per time

Sampling interval

1~999min(Adjustable)

Rotating speed

710r/min

Reducer

250

Speed ratio

23.34

Power

2.2kw

Model No. of Motor

Y132S-8

Working voltage

380V, 50HZ

Total weight

1100kg

Time control

Controlled by time relay and travel switch

Protection standard

IP55



Machanized Belt End Stream Cutting Sampler
