Double Lock Dual Cylinder Hydraulic 4T Economical Floor Plate Two Post Auto Lift Hoists

Specifications

Auto Lift Hoists
1. Lifting Capacity: 4T(9,000lbs)
2. Lifting Height: 2000mm
3. Double Lock Dual Cylinder
4. CE Approved

Auto Lift Hoists



L-2-40D is a floor plate doulbe lock release two post lift designed for low ceiling garages. The total column height of  2826mm(9.3'/111")  allows this lift to be installed in almost any professional or home garage with a ceiling as low as 2900mm(9' 6").







Description:



8 Folds post design, Double Cylinder Drive Design
Double Lock Release System
Lifting Capacity: 4.5T(10000lb)
Max. Lifting Height: 2000mm( 6.6'/78.7" )
Height Overall: 2826mm(9.3'/111")
Width Overall: 3418mm(11.2'/134.5")
Rise Time: 50s
Width between Pillars: 2865mm(9.4'/113")
Power Supply: 3PH/380V







Package:



2820*520*860mm
840*290*340mm
Net weigth: 670Kg
24units/20'





Production:




Warranty:





J&F 2 post lifts, alignment lifts, parking lifts, mid-rise lifts, scissor lifts, and high-rise lifts are warranted for five (5) years on structural components and one (1) year on electric or air / hydraulic power units and cylinders effective from date of invoice.





J&F Certifications:
