Specifications
The apparatus consists of slump cone with handles and foot pieces.Concrete slump cone set
The test apparatus is carried out by filling the slump cone with freshly mixed concrete which is tamped with a steel rod in three layers. The concrete is levelled off with the top of the slump cone, the cone removed, and the slump of the sample is immediately measured.
To ensure that concrete achieves its maximum possible strength and yet retains its ease of placing on site, it is essential that the design of the concrete mix, in relation to the water-cement ratio and workability, is closely controlled.
We propose two different models: the standard one particularly suitable for laboratory testing and the portable model very practical for site testing. A number of parts and accessories are however available for particular requirements.
SM series Slump Cone
SM-R3 Steel rule 300 mm long
SM-R5 Steel rule 500 mm long (user selectable)
SM-BP40 Metal base plate 400x400x40 mm
SM-F Slump cone funnel
SC-R24 Scoop
TR-S600 Steel tamping rod, dia.16 x 600 mm
TR-S380 Metal tamping bar, 25 x 380 mm long(user selectable)
