Product Details
Place of Origin: | Hebei, China | Brand Name: | YFT | Model Number: | hhyft-NS-101 |
Product Description
Factory Price of Square Nail Stakes/Round Nail Stakes
1.Specifications:
1.steel Q235
2.the tip of pencil is black powder coated ;
the Marquise-cut diamond is gray powder coated;
the primary will be coated oil.
3.Size
1) diameter : Flat Stake:1-1/2" X3/8" length: 12"18"24"30"36"42"48"
2) diameter :Square Stake :5/8" length: 12"18"24"30"36"42"48"
3) diameter :Round Stake :3/4" length: 12"18"24"30"36"42"48"
7/8" length: 12"18"24"30"36"42"48"
1.10pcs/bdl,about one ton per pallet
3 Detail Specification:
C-Type Steel Stake | unit:inch | TOLERANCE | ±0.12 | ±0.12 | ±0.12 | ±0.16 | ±0.16 | ±0.2 | ±0.2 |
| TOTAL LENGTH(L) | 12 | 18 | 24 | 30 | 36 | 42 | 48 | |
| NO.OF.HOLES | 4 | 7 | 9 | 12 | 16 | 16 | 16 | |
| unit:CM |
|
|
|
|
|
|
|
|
|
| TOLERANCE | ±0.3 | ±0.3 | ±0.3 | ±0.4 | ±0.4 | ±0.5 | ±0.5 |
|
| TOTAL LENGTH(L) | 30.48 | 45.72 | 60.96 | 76.2 | 91.44 | 106.68 | 121.96 |
|
| NO.OF.HOLES | 4 | 7 | 9 | 12 | 16 | 16 | 16 |
|
|
|
|
|
|
|
|
|
|
Square Steel Stake | unit:inch | TOLERANCE | ±0.12 | ±0.12 | ±0.12 | ±0.16 | ±0.16 | ±0.2 | ±0.2 |
|
| TOTAL LENGTH(L) | 12 | 18 | 24 | 30 | 36 | 42 | 48 |
|
| NO.OF.HOLES | 4 | 9 | 13 | 15 | 21 | 21 | 21 |
| unit:CM |
|
|
|
|
|
|
|
|
|
| TOLERANCE | ±0.3 | ±0.3 | ±0.3 | ±0.4 | ±0.4 | ±0.5 | ±0.5 |
|
| TOTAL LENGTH(L) | 30.48 | 45.72 | 60.96 | 76.2 | 91.44 | 106.68 | 121.96 |
|
| NO.OF.HOLES | 4 | 9 | 13 | 15 | 21 | 21 | 21 |
|
|
|
|
|
|
|
|
|
|
ROUND STEEL STAKE | unit:inch | TOLERANCE | ±0.12 | ±0.12 | ±0.12 | ±0.16 | ±0.16 | ±0.2 | ±0.2 |
|
| TOTAL LENGTH(L) | 12 | 18 | 24 | 30 | 36 | 42 | 48 |
|
| NO.OF.HOLES | 4 | 8 | 10 | 12 | 14 | 14 | 14 |
| unit:CM |
|
|
|
|
|
|
|
|
|
| TOLERANCE | ±0.3 | ±0.3 | ±0.3 | ±0.4 | ±0.4 | ±0.5 | ±0.5 |
|
| TOTAL LENGTH(L) | 30.48 | 45.72 | 60.96 | 76.2 | 91.44 | 106.68 | 121.96 |
|
| NO.OF.HOLES | 4 | 8 | 10 | 12 | 14 | 14 | 14 |
