Home > Electrical & Electronics > Sensor > Pressure Sensor > ABS Wheel Speed Sensor

ABS Wheel Speed Sensor

ABS Wheel Speed Sensor thumbnail-1
ABS Wheel Speed Sensor photo-1
US$ 3.4 - 5 MOQ: 100 Pieces
Key Specifications
Get Latest Price
Type:
Wheel Speed Sensor
Size:
dia.70mm*51mm
Car Make:
Opel and Fiat
Contact Supplier Request Quote Chat Now
Ningbo Apexes Import & Export Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo or Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Wheel Speed Sensor
Size dia.70mm*51mm
Car Make Opel and Fiat
OE NO. 1604314/93170611
Place of Origin Zhejiang, China
Model Number 1604314/93170611
Warranty 1 Years

Specifications

This is a sensor for automobile wheel speed, output square wave signal of normal, guest feedback was good.

This is a ABS wheel speed sensor, the main performance is as follows:

1,Thermal range of application for sensor: -40°C---125°C;

2,Product installation dimensions: this installation dimensions in the outershell  diameter, size 65.8mm, tolerance for ( +0.1, 0);

3, Operation frequency range: 1Hz---2500Hz;

4, DC Power Input : 5.5V---24V;

5, Out Put Ratio: 50% ± 20% ;

6, High State Output : 11.2mA---16.8mA;

7, Low State Output : 5.6mA---8.4mA;

8, Operation Air Gap: 0---1.5mm;

9,Quality Assurance: 1Year (20.000KM).

The products are used in Car models are:   Opel Car and Fiat Car
