Concrete Pile Cutting Machine in Construction Machinery Parts

FOB Price

USD $2,250 - $2,500 / Set

1 Set(Min.Order)

Supply Ability 100 Set / Sets per Month
Port Ningbo Shanghai Qindao
Payment Terms:T/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Place of Origin:

Jiangsu, China

Brand Name:

RAY

Model Number:

SP500

Product Description

Concrete Pile Cutting Machine in Construction Machinery Parts

Do you tired to break the piles by manpower? Dangerous , Slowly , Noisy , Expensive salary and so on.

Don’t worry. Ray pile breaker will help you!

Your problems	How can we solve it?
Dangerous	1. Contact-free operation is enabled. 2. And it imposes no impact force on the parent body of the pile and no influence on the bearing capacity of the pile.
Slowly	1.Replaceable and changeable module combination makes its applicable for piles with various diameters. 2.The modules can be assembled and disassembled easily and conveniently.
Noisy	Its full hydraulic drive causes little noises during operation and no influence on the surrounding environments
Expensive salary	1.Fewer operating workers are required to save cost for labor and machines maintenance during construction. 2.Suitable for different kinds of carrier. 3.Module generalization is realized with our SP380 and SP400-B square pile machine. It can be used for both circular piles and square piles by changing the module combination
Durable?	1. It is made of military material by first-class suppliers with reliable quality, extending its service life. 2.The mainboard used Q345B and the chisel used the 42Crmo. 3.12 month after-sales service. 4.Provide 50 spring pins for free. 5.Professional small tools for free.

Details

(1) The mechanical stress is put pressure on the structural parts not on the connection when it worked and the oil cylinder which is specially-made by Sany used the double oil seal.

(2) There are 7 kinds of pin axle holes to match different shaft. To prevent the form of pile breaker changed when it worked.

(3)The shackle loading weight is 3 tons .Meet the national standards.

(4)The chain hoist is adjustable and the loading weight is 4 tons.

Product option

SP606/380 SP400-A SP400-B SP500

Parameter Sheet

Model	SP606	SP380	SP400-A	SP400-B	SP500
Range of pile diametre(mm)	1700-1850	950-1050	300-400mm	300-400mm	400-500mm
Maximum drill rod pressure	690KN	320KN	320KN	320KN	320KN
Maximum stroke of hydraulic cylinder	180mm	150mm	150mm	150mm	150mm
Maximum pressure of hydraulic cylinder	34.3Mpa	34.3Mpa	34.3Mpa	34.3Mpa	34.3Mpa
Maximum flow single cylinder	25L/min	25L/mim	25L/mim	25L/mim	25L/mim
Cut the number of pile/8h	40-100	60	160	160	120
Height for cut pile each time	≤300mm	≤300mm	≤300mm	≤300mm	≤300mm
Supporting the digging machine tonnage(excavator)	≥35T	≥20T	≥7T	≥8T	≥15T
One-piece module weight	280kg	110kg	/	110kg	200kg
One-piece module size	*908680380*	*604594286*	/	*604594286*	*595980275*
Work status dimensions	*32003000**	*22682500**	*144014401500*	*160016002000*	*171017102500*
Total pile breaker weight	3.7T	1.5t	600KG	650KG	960KG

Factory and Equipment

Applications: We complete project outdoor with high efficiency and much safty.

Packaging

Company profile

1.13 years experience in producing and serving.

2. We are a factory with authorized Imp & Exp .

3. Nearby Shanghai and Ningbo, convenient Transportation.

4. Awarded ISO9001-2000 certificate and also CE certificate.

5. Integration and Innovation, Cooperation and Forward Together is RAYMOND’s spirit.

Exquisite Technology, Honesty Forever is RAYMOND’s concept.

Quality Supremacy, Customer First id RAYMOND’s pursue

Contact Us

Changzhou Chuangcheng Precision Machinery Co., Ltd.: Contact nameRaymond Yue; Phone0086-519-88522885; AddressWujin Changzhou,Jiangsu
