Home > Products > Electric Bike > 12inch Fashion Model;36v electrical bicycle ; portable e bike; Lithium battery; with Aluminium Alloy Frame

12inch Fashion Model;36v electrical bicycle ; portable e bike; Lithium battery; with Aluminium Alloy Frame

FOB Price

Negotiable / Piece

10 Pieces(Min.Order)

Supply Ability 0 per Month
Port Shanghai
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Wattage	200 - 250w	Voltage	36V
Power Supply	Lithium Battery	Wheel Size	Other, 12”
Motor	Brushless	Certification	CE
Frame Material	Aluminum Alloy	Foldable	Yes
Max Speed	Other, <30km/h	Range per Power	31 - 60 km
Place of Origin	Jiangsu, China	Brand Name	Factory's brand
Model Number	TDW02III

Product Description

Specifications

1. Fast and easy folding without tools
2. Aluminium Alloy and Magnesium Alloy
3. Lithium battery, 800 times life battery

Folding E Bike

12inch Comfort

V brake front &

Roller brake rear

12inch Fashion

V brake front &

Roller brake rear

12inch Luxury A

Disc brake front &

Disc brake rear

12inch Luxury B

V brake front &

Special roller brake for

Shimano inner 3 speed

12inch Torque Sensor

Disc brake front &

Disc brake rear

16inch Comfort

V brake front &

Roller brake rear

16inch Luxury A

Disc brake front&

Disc brake rear

12inch Luxury B

V brake front &

Special roller brake for

Shimano inner 3 speed

16inch Torque Sensor

+ Shimano Gear

Disc brake front &

Special roller brake

for Shimano inner 3 speed

Product Description

Folding E-bike 12inch Fashion Model(Oxidation Treatment)
MODEL# ITEMS		TDW02ZⅢ
Basic Spec.	Material	Aluminum Alloy and Magnesium Alloy
	Treatment	Anodic Oxidation
	Unfold Size(mm)	1260 × 550 × 1090
	Folding Size(mm)	610 × 275 × 810
	Packing size(mm)	620×280×835
	Center Distance of Front and Rear Wheels	980mm
	Overall Height	109cm
	Net Weight(not including the batterry)	16kgs
	Max Speed(km/h)	25 km/h
	Battery-full charge range (Electic drive/ Pedal-operated booster)	30~40 km / 50~60 km
	Max Load	110kgs
	Front Brake	V Brake
	Rear Brake	Roller Brake
	Head Lamp	LED
Battery Spec.	Type	Lithium Battery (Scud)
	Battery Capacity	9 Ah (net weight: 2.4 kg)
	Nominal Voltage	36 V
	Charge Time	3~5 hours
Motor Spec.	Type	Brushless Motor
	Rated Power	200 W / 250 W
	Rated RPM	235 r/min
	Rated Voltage	36V
	Rated Torque	6 Nm
	Traction	front wheel drive
Controller Spec.	Undervoltage Protection Value	28.5 ± 1 V
	Current Limiting Protection Value	11 ± 1.5 A
	Powered by	Front wheel powered by Battery; Rear wheel powered by Pedal
	Controller
Colour	Colour Optional	Golden/white-black
Certificate		CE, EN15194R, ISO9001-2008
Packing	G.W./CTN(KGS)	23
Packing	QTY FOR 1X20GP/1X40GP(PCS)	198/396
