Angle Clamp Aluminum Angle Clamp Corner Clamp

angle clamp aluminum angle clamp  corner clamp

Jaw width: 65mm

Jaw opening: 75mm (3")

Angle: 45-180  degree

size:  6"Lx7"x2.5"H

Adjusting the angle of the clamp

1. To adjust the angle use a Phillips screwdriver and loosen screw (A) holding the clamp.

2. Adjust to the desired angle and tighten the screw.

Placing the corners in the clamp

1. Place the pieces to be joined together into the clamps

2. Tighten the clamps by turning the handles (B) to hold the pieces in place.

Using the saw guider

1. Align the notch on the front of the saw guider (C) with the desired degree angle and tighten the screw on the saw guider (C).

2. Then loosen Screw (D) to loosen the bracket and fit it to the width of your saw blade

3. Place the saw blade in-between the bracket and begin to saw.

Mounting Corner clamp on workbench - (Optional)

1. The corner clamp may be mounted on a workbench

2. Use two screws (not included) and insert them into the mounting holes.

3. Use a drill (not included) and drill the two screws down to secure the corner clamp to your work  bench.
