NC Brush Drilling and Tufting Machine3-Axis
X-Y stroke:600mm*240mm;
Type of motor:servo motor.
3-Axis NC Brush Drilling and Tufting Machine
CP-2008MTL75HDS
1,The maximum length of roller brush can be up to 600mm
2,Newly designed bristle feeding mechanism without using bristle carrier spring blade, so that getting bristle would be more stable and durable
3,An automatic electric oil pump is equipped in the tuft head for motion part lubrication so as to lengthening the lifetime of parts, lubricating oil is supply and recollected to filter then use in recycle
4,Easy to changeover for different rollers making(for similar roller, it required only for the clamping parts to be changed), easy and simple operation
Parameters:
1,Axis:3 axis
2,X-Y stroke:600mm*240mm
3,Z rotation:360o
4,Type of motor:servo motor
5,X,Y driving screw:precision ball screw
6,X-Y guide way:LM guide
7,X-Y position accuracy:±0.01mm/100mm
8,Drilling spindle speed:15000RPM
9,Air input:air can be adjusted within 1-8bar
10,Main power input:3 phase 346v
11,Power consumption:3500w
12,Bristle container:double color bristle container
13,Diameter of drilling tufting hole:ø3.0-8.0mm
14,Tufting length:50-150mm(max length of bristle)
15,Tufting method:staple type
16,Tufting speed:3-4 holes/sec
17,Machine size:2150mm*1380mm*2140mm
18,Controller size:700mm*480mm*1360mm
19,Duster size:1140mm*600mm*1200mm
20,Machine gross weight:2500kg
21,Controller gross weight:150kg
22,Duster gross weight:150kg
Touch screen display machine special features:
1,It is provided with manual data input as well as teach in data input method
2,Auto or step operation
3,Speed of drilling is controlled inverter for various speed adjustment
4,Test mode to test machine of functions properly
5,Editing features of insert, delete or copy
6,Normal working of positioning testing
7,Drilling/Tufting excessive pressure alarm
8,Complete touchable screen display for easy data editing and operating
9,According to requirement, the display can be set at factory for Chinese or English display
10,Data can be saved up to U disk that can be used with PC for data retrieval
11,Each brush for work up to 1000 holes
12,During auto run mode, it can be paused for missed holes reworking
13,Alarm display when problem occurred
