Auto Starter Battery 12v 3.3Ah

Name: Auto Starter Battery 12v 3.3Ah
Brand: OCELL
SKU: 143103216

US$ 88 - 88 MOQ: 1000 Pieces

Key Specifications

Brand Name:

OCELL

Model Number:

12V 3.3Ah

Type:

Li-Ion

Ocell New Energy Technology Co., Ltd.

6Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Brand Name OCELL

Model Number 12V 3.3Ah

Type Li-Ion

Nominal Voltage 1.2V

Size Prismatic

Nominal Capacity 3.3Ah

Specifications

Normal Voltage: 12v
Normal Capacity: 3.3Ah
Max continuous discharge current: 20C(60A)
Max Peak: 50C (160A/3s)

No.	Item	General Parameter	Remark
1	Rated Capacity	3.3Ah	Standard discharge(1 C) after standard charge (1C)
2	Minimal Rated Capacity	3.0Ah	Standard discharge(1 C) after standard charge (1C)
3	Nominal Voltage	12.8V
4	Cycle Life	Higher than 60% of the Initial Capacity of the Cells	Charge: CC@1C to 14.6V, then CV till current to 0.05C Rest: 30min. Discharge: 1C to 8.0V Temperature:20±5°C Carry out 800cycles
5	Discharge cut-off voltage	8.0V( recommended)	When the Voltage is low than 8V,the alarm circuit will open and the buzzer will alarm.
6	Charging cut-off voltage	14.6V (recommended)
7	Cell and assembly method	IFR18650EC-1.1Ah	4S3P
8	Housing material	PVC

No.	Item	General Parameter	Remark
9	Standard charge	1C constant current(CC) charge to 14.6V,then constant voltage (CV)14.6V charge till charge current decline to ≤0.05C	Charge time : Approx 1.5h
10	Standard discharge	Constant current 20C Cut-off voltage 8.0V
11	Maximum Charge Current	5CA	1CA or less recommended for better performance and life
12	Continuous Discharge Current	20CA ( the temperature of cells is not exceed 80°C)	Over current 50CA 3S ( the temperature of cells is not exceed 80°C)
13	Operation Temperature Range	Charge: 0~45°C	60±25%R.H.
13	Operation Temperature Range	Discharge: -10~60°C	60±25%R.H.
14	Storage Temperature Range	Less than 1 year : 0~25°C	60±25%R.H. at the shipment state
14	Storage Temperature Range	Less than 3 months:-5~35°C	60±25%R.H. at the shipment state
15	Weight	Approx: 0.75Kg
16	Pack Dimension	Height:75mm
		Width: 40mm
		Length: 120mm
