12V40AH LiFePO4 battery for SOLAR STORAGE
Advantages:
Application: 12V40AH battery modules with PCM included, it can be make battery solution in serials and parallel to reach high voltage and capacity.
Battery Comparison:
- Smaller size,normally 1/3 as large as conventional SLA battery;
- Lighter weight,normally 1/3 as conventional SLA battery;
- Longer cycle-life,SLA battery is about 300cycles while LiFePO4 battery can be 1000 cycles or more;
- Good performance in deep discharge,LiFePO4 battery can be 100%DOD while SLA battery is 60%∼80%DOD,which means LiFePO4 battery will need less capacity in the same condition;
- Totally environmental-friendly.
contact sales11 AT for more details.
O'CELL 12V40Ah Solar Battery Pack
Usage Notes:
Our 12V40Ah module, with nominal voltage of 12.8V and capacity of 40Ah is assembled with high power LiFePo4 cells.It can be used individually and can be connected in serial or parallel to achieve given voltage and capacity.
Features:
a. Extremely safe and stable chemistry: PCB and/or BMS built inside to balance protect the battery.
b. Long life-cycle: Can be circularly used, best can up to 2000 times recycles, 8 times of Lead acid battery.
c. Lighter weight, with the best power-to-weight ratio: 1/3 of Lead acid battery weight.
d. Good performance at high temperature and high temperature resistance
e. Low self-discharge rate, less than 3% monthly.
f. No memory effects and highly efficient charge.
g. Environment friendly: Clean and Green energy poses no pollution on our environment.
Item |
Unit |
Specifications |
Nominal Capacity |
Ah |
40.0 |
Nominal Voltage |
Voltage |
12.8 |
DimensionH×W×L |
mm |
195×130×183mm |
Weight |
kg |
6.8 |
Charge Cut-off Voltage |
Voltage |
14.6 |
Discharge Cut-off Voltage |
Voltage |
10.0 |
Max. Continue Discharging |
Amps |
20.0 |
Internal Resistance |
mΩ |
<15 mΩ |
Working Temperature (Charging) |
oC |
0oC--45oC |
Working Temperature (Discharging) |
oC |
-20oC--60oC |
Relative Humidity |
N/A |
45%--75%RH |
