Specifications
36V 15AH Rear rack battery for electric bicycleMaterial:LiNiCnMnO
Dimention: 69*148*352mm
1.stable and safe
2.long cycle
36V 15AH Rear rack battery for electric bicycle
Material:LiNiCoMnO
Dimention: 69*148*352mm
1.stable and safe
2.long cycle life
LiFePO4 battery specification:
Product specification parameter | ||
Model |
INR36/15 |
|
Capacity(0.2 C5A) |
15Ah |
|
Nominal Voltage |
36V |
|
Charge Voltage |
42V |
|
Discharge Cut-off Voltage |
25V |
|
Standard charge current |
2A(0.2 C5A) |
|
Max. continuous discharge current |
20A (2 C5A) |
|
Max. pulse discharge current(≤1s) |
30A (3 C5A) |
|
Battery Structure |
10S7P(Add PCM ) |
|
Packaging Shell |
Rear rack |
|
Weight (Approx.) |
5±0.05kg |
|
Dimensions(Approx.) |
L352mm*W148mm*69mm |
|
Impedance (Max, at 1000Hz) |
210mΩ±10 |
|
Cycle Life(80DOD%) |
≥500 times |
|
Self-discharge Rate |
≤3% |
|
Charge Method (CC/CV) |
Standard |
0.2C5A×6.5 hr. |
Quick |
1 C5A×2.5 hr. |
|
Operating Temperature |
Charge |
0°C~45°C,32oF~113oF |
Discharge |
-10°C~60°C, -4oF~149oF |
|
Storage |
-20°C~45°C, -4oF~113oF |
|
Charger Specification:
1. Output: 36V DC 2A
2. Input: 100-240VAC (As your country's standard)
Packing List:
1) 1pack 36V15Ah Battery (Aluminum Alloy Shell)
2) 1pcs 36V 10A-20A BMS
3) 1pcs 36V2Amps Alloy Charger
4) Key and other parts
Features:
1) Long cycle life
2) Maintenance-free operation
3) Good safety performance
4) Low self-discharge and fast charge
5) Environment friendly
6) High capability and stability
7) Broad operating temperature range: discharge temperature: -20-60°c
Battery quality:
1.Cells: A grade cells to make sure batteries in high and full capacity
2.Protection: Dual IC chips, that can anti-short-circuit, anti-overcharge, anti-over current, anti-overload
3.Compose Type : Injection Technology to make battery more stable
4.Certifications : CE,UL,FCC, RoHS,ISO9001
5. Long life cycly, No memory, environment friendly
We can provide 18650 battery pack
24v, 36v, 48V battery with different capacity are available for E-bike, the battery can be customize per customer request.
If you have any question, please feel free to contact Coco Guo.
:)
