36v 9ah Lifepo4 Electric Bicycle Battery

Name: 36v 9ah Lifepo4 Electric Bicycle Battery
Brand: O'cell
SKU: 143102728
Availability: InStock

US$ 1 - 300 MOQ: 1 Piece

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

O'cell

Model Number:

36V9Ah

Ocell New Energy Technology Co., Ltd.

5Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name O'cell

Model Number 36V9Ah

Composed Type Other, Series and Parallel

Type Li-Ion

Components Other, LiFePO4

Size 76*110*388mm

Voltage 36V

Weight 4.6kg

Nominal Capacity 9AH

Application E-BIKE

Specifications

lifepo4 battery 36v 9ah for E-bicycle
1. Intelligent charger
2.environmentally friendly
3.long cycle-life

This battery pack is designed for application of E-bike, with intellegent BMS and charger, multiple protections on short circuit

Features of lifepo4 battery 36v 9ah for E-bicycle

1. Constituted by 26650 cells which are the most reliable ones under mass production.

2. Intelligent balance charging is offered in the battery management system ( BMS ).

3. Intelligent charger.

4. Control on each single cell is realized, so that the whole battery pack can work longer and better.

5. Multiple protections on short circuit, reverse connection and over-heat are provided to keep the battery pack in a safe state.

Item	Spec
Nominal Voltage	36V
Nominal Capacity	9Ah
Min. Capacity	8Ah
Relative humidity	≤85%
Weight	4.6KG±0.5Kg
Size	76110388mm
Standard Charge	Specialized charger: 3.5A/45V
Standard Charge Method	Constant 1/3C to 44V, then constant 44V with current taper to C/10
Max. Charge Current	1C
Continuous Discharge Current	1C
Peak Discharging Current (10S)	10C
Min Discharge Voltage	20V
Life Cycle ( 2C 80% DOD)	1000
Life Cycle ( 1C 80% DOD)	2000
Charging	0-60
Temp. Range Discharging	-20-70
Storage	-40-70
Warranty	1 year
