O'CELL 12V9Ah LiFePo4 Battery Pack with SLA Case
Usage Notes:
Our OL12V90F module, with nominal voltage of 12V and capacity of 9Ah is assembled with high power LiFePo4 cells.It can be used individually and can be connected in serial or parallel to achieve given voltage and capacity.
Features:
a. Extremely safe and stable chemistry: PCB and/or BMS built inside to balance protect the battery.
b. Long life-cycle: Can be circularly used, best can up to 2000 times recycles, 8 times of Lead acid battery.
c. Lighter weight, with the best power-to-weight ratio: 1/3 of Lead acid battery weight.
d. Good performance at high temperature and high temperature resistance
e. Low self-discharge rate, less than 3% monthly.
f. No memory effects and highly efficient charge.
g. Environment friendly: Clean and Green energy poses no pollution on our environment.
Item |
Unit |
Specifications |
Nominal Capacity |
Ah |
9.0 |
Nominal Voltage |
Voltage |
12.0 |
Dimension |
mm |
110×90×70mm |
Weight |
kg |
1.1 |
Cut-Off Charge Voltage |
Voltage |
14.6 |
Cut-Off Discharge Voltage |
Voltage |
10.0 |
Standard Discharge Amperage |
Amps |
9.0 |
Rated Discharge Amperage |
Amps |
27.0 |
Standard Charge Current |
Amps |
4.5 |
Rated Charge Current |
Amps |
9.0 |
Storage Temperature Range |
oC |
-20oC--70oC |
Working Temperature (Charging) |
oC |
-10oC--45oC |
Working Temperature (Discharging) |
oC |
-20oC--60oC |
Relative Humidity |
N/A |
45%--75%RH |
Life Cycle(2C,80%DOD) |
|
1000 |
Life Cycle(1C,80%DOD) |
|
2000 |
Warranty |
Year |
1 |
