Home > Products > LiFePO4 Battery for ESS > 48V40Ah LiFePO4 battery for Storage Energy System
48V40Ah LiFePO4 battery for Storage Energy System
- 10000 Pack / Packs per Month
- Shenzhen HK
- T/T
Product Details
Place of Origin: | Hubei, China | Brand Name: | OCELL | Model Number: | IFM48-400E3 |
Composed Type: | Other, 16S12P | Type: | Li-Ion | Components: | Other, LiFePO4/Lithium |
Size: | 270x156x348mm | Voltage: | 48V | Weight: | 17KG |
Nominal Capacity: | 40AH | Application: | E-boat, e-scooter, AGV |
Packaging Details
Standard export package
Product Description
LiFePO4/Lithium/li-ion battery 48V40Ah for energy storage system, solar system, AGV, HESS, e-boat...
1. Specification
Item | Unit | Specifications |
Typical Capacity | Ah | 40AH |
Minimum Capacity | Ah | 38AH |
Nominal Voltage | Voltage | 51.2V |
Dimension (L*W*H) | mm | 270x156x348mm |
Approx.Weight | kg | 17 |
Max. Charge Voltage | Voltage | 58.4V |
Cut-Off Discharge Voltage | Voltage | 40V |
Standard Charge Current | Amps | 8A |
Rapid Charge Current | Amps | 20A(adjustable) |
Continuous Discharge Current | Amps | 40A (adjustable) |
Pulse Discharge Current(5S) | Amps | 80A (adjustable) |
Storage Temperature Range | oC | -20oC--60oC |
Working Temperature (Charging) | oC | -10oC--45oC |
Working Temperature (Discharging) | oC | -20oC--60oC |
Life Cycle(1C,80%DOD) | Times | 2000 |
The motor power?
Your expected working time?
What's your max dimension?
2. Characteristics:
1,Low temperature and strong, self-discharge, long life.
2,Stable high-current discharge characteristics, charge a good reception.
3,Contained acid gel batteries with the lock acid capacity, water loss rate is small, non-mist gas precipitation, no electrolyte spillage and stratification, can effectively improve the stability of the battery than the capacity, cycle times and long.
4,Three generations of silicone cell cycles, second-generation gel battery life of more than 40% above the normal use of electric vehicles can be more than two years
3. Battery quality:
1. Cells: A grade cells to make sure batteries in high and full capacity
2.Protection: Dual IC chips,that can anti-shortcircuit, anti-overcharger, anti-overcurrent, anti-overload
3.Compose Type : Injection Technology to make battery more stable
4.Certifications : CE,UL,FCC, RoHS,ISO9001
5. Long life cycly, No memory, environment friendly
We can provide 6V-72V 10-100AH power tools battery pack
4. Shipment:
TNT, DHL, FedEx
5.Safety Precaution:
1.Do not throw battery into water or make it wet;
2.Keep the battery away from heat source(like fire or heater);
3.Do not throw the battery into fire or heat the battery;
4.Forbid to hammer to trample the battery;
5.Forbid disassembling the battery in anyway
6. About us (OCELLTechnology Co., Ltd):
1.Professional lithium-ion battery manufacturer for over 5 years.
2.Strong R&d team to support.
3.Also provide best UL approved cell.
4.BMS solution come from brand PCM.
5.Offer OEM service for customer small order.
6.Quickly action & respond.
7.Best sale service and good price.
Our company specialized in LiFePO4 battery according to the customer request.
More support, pls feel free to contact Kathryn Wang with below:
Tel: +86-755-81781377 Ext. 8007
Fax: +86-755-81781420
Mobile: +86-18998906372
Skype: tethy03
24V50AH photo:
36V20AH battery
Factory overview:
Kathryn Wang
Shenzhen OCELL Technology Co., Ltd
Tel: +86-755-81781377 Ext. 8007
Fax: +86-755-81781420
Email: sales02(at)ocelltech(dot)com
Web:
Company Address :
Bld.,B3, Donghao Industrial Park, Sili Road, Guanlan Town, Longhua District,Shenzhen,Guangdong,518110,China.
Factory Address:
O'CELL Industrial Park.Yayuan Road,Xiaoting District,Yichang,Hubei,443007 China.
OEM&ODM are available upon request. Warmly welcome your inquiry.
Company Profile
O'CELL New Energy Technology Co., Ltd., established in Oct.2008, is a high-tech enterprise which involves in research, production, sales and services of qualified Lithium Iron Phosphate (LiFePO4) cell, battery pack, reliable battery management system and one-stop power solution, for a wide range of applications worldwide including HEV, EV, AGV, Solar & Wind Power Generation System, UPS, Lighting, Toys, etc.
O'CELL's manufacturing facilities are ISO9001:2008 and ISO14001:2004 registered. It's products are compliant with CE, RoHS and have passed UN transportation testing, which is required for international transportation of all lithium batteries.
O'CELL people are the engine of our success today and in the future. They are motivated to keep well informed about the most recent technological developments and modernization management. Meanwhile, O'CELL continues to invest in research and development in order to take a leadership role in advanced lithium battery technology.
O'CELL factory covers over than 96,000m2 and bases in Yichang which is famous for Three Gorges and the biggest water power center in the world. Taking the advantage of sufficient electricity, O'CELL will pass the benefit to our customers. O'CELL sincerely expects to cooperate with our customers for mutual benefit and common development. O'CELL also hopes that we can contribute to new energy development and green circular economy.
