Home > Products > LiFePO4 Battery for AGV > LiFePO4 12V7.5Ah battery pack
LiFePO4 12V7.5Ah battery pack
- 2000 Set / Sets per Month
- SHENZHEN
Product Details
Place of Origin: | Guangdong, China | Brand Name: | O'cell | Model Number: | 12V7.5Ah |
Type: | Li-Ion | Nominal Voltage: | 12V | Size: | Other, 28*71*94mm |
Nominal Capacity: | 7.5Ah |
Packaging Details
Standard Package/Compact design
Product Description
Specifications
1,Ultra-Longer Lifecycle-2000times2,Lighter Weight,Smaller Size
3,Higher Safety
4,Free Maintenance
O'CELL 12V7.5Ah LiFePo4 Battery Pack with SLA Case
Usage Notes:
Our OL12V75F module, with nominal voltage of 12V and capacity of 7.5Ah is assembled with high power LiFePo4 cells.It can be used individually and can be connected in serial or parallel to achieve given voltage and capacity.
Features:
a. Extremely safe and stable chemistry: PCB and/or BMS built inside to balance protect the battery.
b. Long life-cycle: Can be circularly used, best can up to 2000 times recycles, 8 times of lead acid battery.
c. Lighter weight, with the best power-to-weight ratio: 1/3 of Lead acid battery weight.
d. Good performance at high temperature and high temperature resistance
e. Low self-discharge rate, less than 3% monthly.
f. No memory effects and highly efficient charge.
g. Environment friendly: Clean and Green energy poses no pollution on our environment.
Item | Unit | Specifications |
Nominal Capacity | Ah | 7.5 |
Nominal Voltage | Voltage | 12.0 |
DimensionH×W×L | mm | 151×65×94mm |
Weight | kg | 1.36 |
Charge Cut-off Voltage | Voltage | 14.6 |
Discharge Cut-off Voltage | Voltage | 10.0 |
Charge current | Amps | 7.5 |
Rated Discharging Amperage | Amps | 15.0 |
Maximum Continue Discharging | Amps | 7.5 |
Internal Resistance | mΩ | <15 mΩ |
Working Temperature (Charging) | oC | -10oC--45oC |
Working Temperature (Discharging) | oC | -20oC--60oC |
Relative Humidity | N/A | 45%--75%RH |
Life Cycle(2C,80%DOD) |
| 1000 |
Life Cycle(1C,80%DOD) |
| 2000 |
Warranty | Year | 1 |
Company Profile
O'CELL New Energy Technology Co., Ltd., established in Oct.2008, is a high-tech enterprise which involves in research, production, sales and services of qualified Lithium Iron Phosphate (LiFePO4) cell, battery pack, reliable battery management system and one-stop power solution, for a wide range of applications worldwide including HEV, EV, AGV, Solar & Wind Power Generation System, UPS, Lighting, Toys, etc.
O'CELL's manufacturing facilities are ISO9001:2008 and ISO14001:2004 registered. It's products are compliant with CE, RoHS and have passed UN transportation testing, which is required for international transportation of all lithium batteries.
O'CELL people are the engine of our success today and in the future. They are motivated to keep well informed about the most recent technological developments and modernization management. Meanwhile, O'CELL continues to invest in research and development in order to take a leadership role in advanced lithium battery technology.
O'CELL factory covers over than 96,000m2 and bases in Yichang which is famous for Three Gorges and the biggest water power center in the world. Taking the advantage of sufficient electricity, O'CELL will pass the benefit to our customers. O'CELL sincerely expects to cooperate with our customers for mutual benefit and common development. O'CELL also hopes that we can contribute to new energy development and green circular economy.
