Manufacture 24V20AH LiFePO4 battery pack with SMbus
Voltage: 24V
Capacity: 20AH
Weight: 5.6Kg
Dimension: 130*183*195mm
Max charge current: 38A (10A recommended)
Over current: 40A
Specification form:
NO. | Items | Specifications |
1 | Charge voltage | 29.3V |
2 | Number of series | 8S6P |
3 | Nominal voltage | 25.6V |
4 | Nominal capacity | 20AH(0.2C discharge) |
5 | Charge current | standard charging: 0.2C |
6 | Rapid charge: 0.5C | |
7 | Charging time | standard charging:6.0 hours |
8 | rapid charge: 3.0 hours | |
9 | Max charge current | 10A |
10 | Max continuous discharge current | 38A |
11 | Discharge cut-off voltage | 20.0V |
12 | Operating temperature | charging: 0°C-45°C |
| discharging: -10°C-45°C |
New Function!
1. SMbus to know more information for battery status
2. Capacity indicator available
3. Fuse for duplicate protection
Application:
Communication: back-up electric supply, interphone
Vehicles: electric bicycle, golf car, electric wheelchair
Power tools: electric cropper, electric drill, electric saw, electric hammer.
Illuminate devices: solar battery, miner lamp, solar street lamp, emergency light, and electric torch, LED lamps and lanterns, traffic signs,
Others: toy, small home appliance, wireless monitoring equipment, Medical instrument equipment, toys, etc
Features:
Pls check below picture for inner configuration:
