Lithium battery pack 24V10AH.
Model: IFM24-100E2
Voltage: 24V
Capaity: 10AH
Con. Discharge current: 1-2C
Max. Discharge current: 3C
Dimension: Customized
Weight: 2.75kg
Structure: 8S3P
Product specification parameter | ||
Model |
LFP24V10AH |
|
Capacity(0.2 C5A) |
10Ah |
|
Nominal Voltage |
24V |
|
Charge Voltage |
29.6V |
|
Discharge Cut-off Voltage |
20V |
|
Standard charge current |
2A(0.2 C5A) |
|
Max. continuous discharge current |
10A (1 C5A) |
|
Max. pulse discharge current(≤1s) |
30A (3 C5A) |
|
Battery Structure |
8S3P(Add PCM) |
|
Packaging Shell |
None |
|
Weight (Approx.) |
3±0.05Kg |
|
Dimensions(Approx.) |
60*140*180mm |
|
Impedance (Max, at 1000Hz) |
100mΩ ±10 |
|
Cycle Life(80DOD%) |
≥1200 |
|
Self-discharge Rate |
≤3% |
|
Charge Method (CC/CV) |
Standard |
0.2C5A×6.5 hr. |
Quick |
1 C5A×2.5 hr. |
|
Operating Temperature |
Charge |
0°C~45°C.32oF~113oF |
Discharge |
-10°C~60°C,-4oF~149oF |
|
Storage |
-20°C~45°C,-4oF~113oF |
|
Features:
a. Extremely safe and stable chemistry: PCB and/or BMS built inside to balance protect the battery.
b. Long life-cycle: Can be circularly used, best can up to 2000 times recycles, 8 times of lead acid battery.
c. Lighter weight, with the best power-to-weight ratio: 1/3 of Lead acid battery weight.
d. Good performance at high temperature and high temperature resistance
e. Low self-discharge rate, less than 3% monthly.
f. No memory effects and highly efficient charge.
g. Environment friendly: Clean and Green energy poses no pollution on our environment
Replacement Policy:
1.We provide one year warranty.
2.If items is defective , please notify us within 3 days of delivery
3.Any items must be returned in their original condition to qualify for a replacement.
4.The buyer is responsible for all the shipping cost incurred.
Contact:
Ms. Kathryn Wang (Sales Manager)
Shenzhen OCELL Technology
Mobile: 86 189 9890 6372
We could customize the current according to your request.
The input plug can be choosed by your preference.
