Home > Electrical & Electronics > Battery, Storage Battery & Charger > Battery Pack > PVC Wrapped 12.8V 9Ah LiFePO4 Battery Pack With Built-in PCB
PVC Wrapped 12.8V 9Ah LiFePO4 Battery Pack With Built-in PCB
US$ 40 - 50
MOQ: 100 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Hubei, China
Brand Name:
O'CELL
Model Number:
IFB12-90E2
Payment & Shipping
Payment Methods:
Port of Shipment:
Yantian Port Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
12.8V 3.3Ah LiFePO4 Lithium Battery Pack & Female Mini Tamiya ConnectorUS$ 15 - 20MOQ: 200 Pieces -
12.8V 110Ah LiFePO4 Battery PackUS$ 570 - 650MOQ: 10 Pieces
-
12.8V 60Ah LiFePO4 Battery PackNegotiableMOQ: 1
-
12.8V 50Ah LiFePO4 Battery PackNegotiableMOQ: 1
-
12.8V 40Ah LiFePO4 Battery PackUS$ 250 - 300MOQ: 20 Pieces
Place of Origin
Hubei, China
Brand Name
O'CELL
Model Number
IFB12-90E2
Composed Type
Other, 4S3P
Type
Li-Ion
Components
Other, IFR26650EC-3.0Ah
Size
159*30*141mm
Voltage
12V
Weight
1.14kg
Nominal Capacity
9Ah
Application
solar lights
1. SPECIFICATION
| No. | Item | General Parameter | Remark |
| 1 | Rated capacity | 9.0Ah | Standard discharge (0.2C) after standard charge (0.2C) |
| 2 | Minimal capacity | 8.55Ah | |
| 3 | Nominal Voltage | 12.8V | |
| 4 | Life Expectation | Higher than 60% of the initial capacity of the cells. | 1) Charge: CC 0.2C to 14.6V, then CV till current to 0.05 C 2) Rest: 30min. 3) Discharge: 0.2C to 10.0V Temperature:20±5℃ Carry out 1,000 cycles |
| 5 | Discharge cut-off voltage | 2.0V/Cell (>8.0V) | 10.0V (recommended) |
| 6 | Charging cut-off voltage | 3.9V/Cell (<15.6V) | 14.6V (recommended) |
| 7 | Assembly methode | IFR26650EC-3.0AH | 4S3P |
| 8 | Housing material | PVC | Flame retardant plastic |
| 9 | Maximum charge current | ≤7A | 3.5A (recommended) |
| 10 | Maximum continuous discharge current | ≤7A | 3.5A (recommended)
|
| 11 | Approx. weight | 1.14kg | |
| 12 | Internal Resistance | ≤115mΩ | |
| 13 | Max. Dimension | Length: 159±3mm. Width: 30±3mm. Height: 141±3mm |
2. PAYMENT
L/C, T/T, Western Union, Paypal.
May you pay 50% deposit in advance, pay off the rest sum when receiving copy of the bill of lading (B/L), please.
3. ADVANTAGES
1). Vertical industry chain brings outstanding cost advantages.
2). O'CELL has integrated and serial product to meet different customers' needs.
3). O'CELL has established strategic ingrates of producing, teaching and research cooperation relationship with HIT/SJTU, ensured the leading position of major techniques.
4). A highly-efficient and professional R&D team is the foundation of building high quality products. Market-oriented research and develop ensure the upcoming products meet customer demands.
5). O'CELL takes geographic advantage of sufficient electricity and mineral resources.
6). Thanks to Integrated Product Development (IPD), O'CELL strengthens product research process and life cycle management.
4. ABOUT O'CELL GROUP
- Established in 2008, one of largest LiFePO4 cathode materials (TOP 10) in China.
- The second company authorized to use Phostech's patented LiFePO4 powder.
- ISO9001:2008 and ISO14004:2004 registered.
- UL listed company.
- Number of Employees: 600.
- Main Products: LiFePO4 cathode material, energy & power LiFePO4 cells, E1 series modular LiFePO4 battery pack, E2 series LiFePO4 battery pack for replacing lead-acid batteries, E3 series smart LiFePO4 battery pack, Battery Monitioring System, one-stop power solution.
- Application: Light electric vehicle, heavy electric vehicle, energy storage, UPS, power tools and so on.
5. CONTACT INFORMATION
- Factory (Yichang O'CELL New Energy Technology Co., Ltd): O'CELL Industry Park in Yichang, Hubei Province, China.
- Sales Center (Shenzhen O'CELL Technology Co., Ltd): Longhua District, 518110, Shenzhen, Guangdong Province, China
- Mr. Fred Yang (sales engineer)
- / sales06(at) / +86-15889298390
