Specifications
Best quality pulse type bag type dust collector
Working principle
This equipment consists of up cylinder(The net gas chamber), middle cylinder(mixing chamber) and the under vertebral body. The air with dust get into cylinder from air inlet, due to the sudden expansion of the volume and flow rate of air flow suddenly reduced, the bigger particles fall into the under vertebral body from the air flow with dust under the gravity force, the smaller particles adsorbed in the outer wall of the bag due to the effects of sieving, collision, diffusion, electrostatic of the bag, the air dusted through bag venturi tube to outside from the outlet of the up cylinder. when the particles of the outer wall of dust increase, so dust resistance increasing, to reduce the resistance, signaled by the Pulse controller to open the electromagnetic pulse valve, compressed air within the package by the respective injection holes injected into the injection tube on the corresponding venturi (primary air), and when the high speed air flow through the venturi tube, lead multiple primary air ambient air(Second air) to the bag, lead to the bag expand rapidly of the moment, as the shock effect of the reverse pulse air quickly disappeared, sharp contraction of the bag, in this case, most of the dust on the bag be clean, fall in to the under vertebral body and discharged.
| Best quality pulse type bag type dust collector | |||||
| item no. | Filtered bag(pc) | bag size(mm) | Filtered erea(m2) | Resistance(mmH2O) | Handle air volume(m3/h) |
| HGP-16 | 16 | 120x1100 | 6.7 | <100 | 270-540 |
| HGP-24 | 24 | 120x1500 | 14 | <100 | 400-800 |
| HGP-31 | 31 | 120x1500 | 17.5 | <100 | 600-1200 |
| HGP-49 | 49 | 120x1500 | 36 | <150 | 1500-2800 |
| HGP-89 | 89 | 120x1500 | 65 | <150 | 2500-4300 |
